Bussmann SC-1/2 Class G 0.5A Ferrule Fuse, 600VAC/170VDC

The Bussmann SC-1/2 is part of the Eaton Bussmann series of Class G general purpose fuses, engineered for current-limiting, fast-acting protection in low-amperage electrical circuits. Rated 0.50A at 600 Vac and 170 Vdc, this fuse features a ferrule end X ferrule end connection with a rejection-style body designed to help prevent installation of an incorrectly rated fuse. Backed by a 100 kAIC interrupt rating at 600 Vac and 10 kAIC at 170 Vdc, the SC-1/2 delivers dependable overcurrent protection for commercial and industrial electrical systems.

Key Features

  • Amperage Rating: 0.50A for precise low-current circuit protection.
  • Class G Construction: Class G sizing fits compact, space-constrained panelboards and load centers.
  • Ferrule End Connection: Ferrule end X ferrule end termination for straightforward installation in compatible fuse holders and blocks.
  • Rejection-Style Body: Rejection-style features help ensure only correctly rated Class G fuses can be installed.
  • Non-Indicating Design: Non-indicating construction (no blown-fuse indicator window).
  • High Interrupt Rating: 100 kAIC at 600 Vac and 10 kAIC at 170 Vdc for high fault-current withstand capability.
  • Dual Voltage Rating: Rated 600 Vac and 170 Vdc for use across AC and DC circuit applications.
  • Current-Limiting, Fast-Acting: Current-limiting, fast-acting operation clears overcurrent conditions rapidly to help protect downstream equipment.

Technical Specifications

  • Amperage Rating: 0.50A
  • Class: Class G
  • Connection: Ferrule end X ferrule end
  • Fuse Indicator: Non Indicating
  • Interrupt Rating: 100 kAIC at 600 Vac, 10 kAIC at 170 Vdc
  • Packaging Type: Standard
  • Special Features: Rejection style
  • Voltage Rating: 600 Vac, 170 Vdc
  • Product Type: Current-limiting, fast acting
  • Product Length: .41 IN
  • Product Details: Current-limiting, fast acting
  • Product Diameter: .41 IN
  • Product Height: 1.31 IN
  • Product Weight: .1 LB
  • Product Width: .41 IN

Typical Applications

  • Panelboard and Load Center Circuit Protection
  • Control Circuit and Equipment Protection
  • Commercial and Industrial Electrical Systems
  • Low-Amperage Branch Circuit Protection

Why Bussmann?

Bussmann by Eaton is a recognized name in circuit protection, and the SC-1/2 reflects that engineering standard with current-limiting, fast-acting performance, a rejection-style Class G body, and a substantial 100 kAIC interrupt rating at 600 Vac. For professionals who need dependable, code-compliant overcurrent protection, the Eaton Bussmann series delivers consistent, reliable performance.

Manufacturer Resources

Product Specs

Amperage Rating:
0.50A
Class:
Class G
Connection:
Ferrule end X ferrule end
Fuse Indicator:
Non Indicating
Interrupt Rating:
100 kAIC at 600 Vac, 10 kAIC at 170 Vdc
Packaging Type:
Standard
Special Features:
Rejection style
Voltage Rating:
600 Vac, 170 Vdc
Product Group:
Fuses
Department:
Electrical
Product Subgroup:
Other Fuses
Product Type:
Fuse
Product Length:
.41 IN
Product Details:
Current-limiting, fast acting
Product Diameter:
.41 IN
Product Height:
1.31 IN
Product Weight:
.1 LB
Product Width:
.41 IN
