Cal Royal Privacy Indicator Leverset, 2-3/8in and 2-3/4in Backset Included, ANSI Strike

Ideal for offices, schools, hospitals, commercial and public buildings, and especially suited for single-stall public restrooms, this Privacy Indicator Leverset offers clear occupancy visibility with a red/green indicator and a commercial-grade design. The leverset comes standard with both 2-3/8" and 2-3/4" backsets and includes an emergency slot on the outside trim for quick access in urgent situations.

Its robust construction includes a stainless steel rose cover and aluminum lever, making it suitable for medium-duty use. Reversible handing and compatibility with multiple door prep sizes make installation simple across a variety of applications.

Function: Privacy with Indicator

Grade: Standard Duty (Commercial Grade)

Indicator: Red (In-Use) and Green (Vacant)

Backset: Includes both 2-3/8" and 2-3/4" options

Door Thickness Range: Adjustable 1-3/8" to 1-3/4"

Handing: Reversible for LH or RH doors

Latch Faceplate: 2-1/4" x 1", includes 1-1/8" plastic filler

Strike: ASA478 ANSI Strike (Standard)

Bore Diameter: 1" latch, 2-1/8" lock housing

Trim: Stainless steel rose cover, aluminum lever

Emergency Release: Emergency slot on outside trim
