Panduit UTPCH1BUY Cat 5e UTP Copper Patch Cord, 1 ft Blue, PoE++ Compatible
The Panduit UTPCH1BUY Cat 5e UTP Copper Patch Cord is a 1 ft blue patch cord built with 24 AWG stranded copper conductors and U/UTP cable construction for reliable Gigabit Ethernet performance. It supports comprehensive PoE/PoE+/PoE++ power delivery, meeting IEEE 802.3af/802.3at/802.3bt type 3 and type 4 standards, and complies with ANSI/TIA-568.2-D and ISO 11801 Class D.
Key Features
- Compact 1 ft Length: Ideal for short-run connections between patch panels, switches, and network gear.
- 24 AWG Stranded Conductors: Flexible, durable copper conductors that maintain signal integrity.
- Category 5e Performance: Exceeds ANSI/TIA-568.2-D and ISO 11801 Class D standards for 1-100 MHz.
- PoE++ Compatibility: Supports IEEE 802.3af/802.3at and 802.3bt type 3 and type 4 PoE applications.
- Durable Construction: PVC jacket with a polycarbonate modular plug housing for reliable handling.
- Dual Wiring Compatibility: Works with both T568A and T568B wiring schemes.
- Wide Operating Range: Rated -10°C to 60°C (14°F to 140°F) for diverse environments.
- CM Flammability Rating: Meets commercial building fire safety requirements.
Certifications & Compliance
- RoHS Compliant
- CM Flammability Rated
- Meets ANSI/TIA-568.2-D Category 5e Standards
- Meets ISO 11801 Class D Standards
Technical Specifications
- Arra Compliant: Y
- Conductor Gauge Awg: 24
- Flammability Rating: CM
- Hazardous Material Flag: N
- Jacket Material: PVC
- Maximum Operating Temperature C: 60
- Maximum Operating Temperature F: 140
- Maximum Storage Temperature C: 70
- Maximum Storage Temperature F: 158
- Mercury Content Indicator: N
- Min Order Qty: 10
- Minimum Operating Temperature C: -10
- Minimum Operating Temperature F: 14
- Minimum Storage Temperature C: -40
- Minimum Storage Temperature F: -40
- Nominal Cable Outside Diameter Mm: 5.5
- Overall Length Ft: 1
- Overall Length M: 0.3
- Rapidid Enabled: Yes
- Reach Status: N
- Std Carton Height In: 3.6
- Std Carton Length In: 9.2
- Std Ctn Qty: 10
- Std Pkg Qty: 1
Typical Applications
- Network Equipment Connections
- Patch Panel to Switch Links
- Workstation Network Access
- PoE Device Power & Data
- Telecommunications Infrastructure
- Data Center Interconnects
Why Panduit?
Panduit delivers proven network connectivity solutions with standards compliance, including ANSI/TIA-568.2-D Category 5e and ISO 11801 Class D certification. RoHS compliant construction and a CM flammability rating support reliable performance in professional installations, while T568A/T568B wiring compatibility and PoE++ support add deployment flexibility.
Manufacturer Resources
Product Specs
- Arra Compliant:
- Y
- Boot Color:
- No Boot
- Cable Construction:
- U/UTP
- Conductor Gauge Awg :
- 24
- Conductor Type:
- Stranded
- Connector 1 Type:
- Modular Plug
- Connector 2 Type:
- Modular Plug
- Country Of Origin:
- Mexico, China, Romania
- Ean:
- 74983062942
- Flammability Rating:
- CM
- Gtin Carton:
- 5.0075E+13
- Gtin Package:
- 74983062942
- Hazardous Material Flag:
- N
- Iec Variant:
- 60603-7
- Jacket Material:
- PVC
- Maximum Operating Temperature C :
- 60
- Maximum Operating Temperature F :
- 140
- Maximum Storage Temperature C :
- 70
- Maximum Storage Temperature F :
- 158
- Mercury Content Indicator:
- N
- Min Order Qty:
- 10
- Minimum Operating Temperature C :
- -10
- Minimum Operating Temperature F :
- 14
- Minimum Storage Temperature C :
- -40
- Minimum Storage Temperature F :
- -40
- Nominal Cable Outside Diameter In :
- 0.215
- Nominal Cable Outside Diameter Mm :
- 5.5
- Overall Length Ft :
- 1
- Overall Length M :
- 0.3
- Pallet Quantity:
- 3,640
- Pallet Volume:
- 55.959636
- Pallet Weight:
- 309.4
- Patch Cord Type:
- Unshielded
- Performance Level:
- Category 5e
- Plug Housing Material:
- Polycarbonate
- Plug Type:
- 8 Position
- Poe Compatibility:
- PoE/PoE+/PoE++
- Product Color:
- Blue
- Product Segment:
- EDI-ENT
- Product Type:
- Patch Cord
- Rapidid Enabled:
- Yes
- Reach Status:
- N
- Rohs Compliant:
- Compliant
- Standard Carton Volume Ft3:
- 0.1537
- Standard Carton Weight Pounds:
- 0.85
- Standard Package Volume Ft3:
- 0.0154
- Standard Package Weight Pounds:
- 0.085
- Std Carton Height In:
- 3.6
- Std Carton Height Mm:
- 91.44
- Std Carton Length In:
- 9.2
- Std Carton Length Mm:
- 233.68
- Std Carton Width In:
- 7.35
- Std Carton Width Mm:
- 186.69
- Std Ctn Qty:
- 10
- Std Package Height In:
- 0.65
- Std Package Height Mm:
- 16.51
- Std Package Length In:
- 6.15
- Std Package Length Mm:
- 156.21
- Std Package Width In:
- 4.95
- Std Package Width Mm:
- 125.73
- Std Pkg Qty :
- 1
- Std Pkg Uom:
- Piece
- Wiring Scheme:
- T568A
- Department:
- Electrical
- Product Group:
- Wiring Devices
