Product Specs
- Inner Dimensions Inches :
- 5.1x7.3x9
- Inner Quantity:
- 5
- Material Housing:
- Other
- Material Quality:
- Other
- Material Sealing:
- No sealing
- Outer Dimensions Inches :
- 18.79x10.8x7.8
- Outer Quantity:
- 20
- Standard:
- UL E23018
- Unspsc:
- 39131707 Electrical conduit coupling
- Weight Uom:
- 106.25 lbs. per 100
- With Outer Thread:
- Y
- Department:
- Electrical
- Product Group:
- Conduit & Fittings
- Product Subgroup:
- Couplings
- Product Type:
- Electrical conduit coupling
- Product Model:
- Straight
- Product Details:
- Chase Nipples
- Product Material:
- Zinc Die Cast
Steel City HA210 – Frequently Asked Questions
1) What is a chase nipple like the Steel City HA210 actually used for?
A chase nipple joins two enclosures or a fitting to a box through a knockout. It is a straight, externally threaded zinc die cast fitting: the threaded end passes through the knockout and a locknut on the far side pulls the two shoulders tight. The HA210 carries no gasket or sealing element, so it is for dry interior work, not wet or raintight locations.
2) Can I use the HA210 chase nipple outdoors or in a wash-down area?
No. The HA210 is supplied with no sealing, meaning no O-ring or gasket, so it will not make a raintight or wet-location joint. For exterior, below-grade, or wash-down enclosures use a sealing locknut and gasketed fitting instead. Indoors in dry locations the bare zinc die cast nipple is fine.
3) Does a locknut come with the Steel City HA210, or do I order that separately?
The HA210 is the nipple only. It has an external thread and no sealing component, so you supply the locknut (and a bushing if the conductors need edge protection) to complete the connection. Order those on the same line so the crew is not short on the job.
4) Is the HA210 a steel nipple or a die cast one, and does that matter for my install?
Zinc die cast, not steel. Die cast zinc is fine for the usual job of bonding two enclosures together through a knockout and is what most chase nipples are, but it is not a substitute for a threaded steel rigid nipple where the fitting has to take mechanical load or span between boxes. Chase nipples are short shoulder-to-shoulder fittings, not running lengths.
5) How many Steel City HA210 chase nipples come in a box?
They pack 5 to the inner carton and 20 to the outer. Worth knowing if you are buying for a stockroom rather than a single panel change-out.
6) What does the Steel City HA210 weigh for a bulk order?
106.25 lbs per 100 pieces. Useful when you are pricing freight on a pallet buy or calculating what a stockroom shelf will carry.
