Square D PowerPacT P I-Line HCR-U Bolt-On Sub-Feed Lug Kit
The Square D PowerPacT P I-Line HCR-U sub-feed lug kit is a UL Listed and CSA certified accessory designed for use on Listed I-Line panelboard equipment. Featuring plug-on jaw construction, this bolt-on sub-feed lug kit plugs directly onto the I-Line bus stack in the same manner as branch circuit breakers, accommodating wire sizes from AWG 3/0 through 600 kcmil at a line rated current of 1200-1200 A. Built for industrial and commercial panelboard applications, it delivers the same reliable connection performance as the equivalent PowerPacT P breaker lugs it complements.
Key Features
- Wire Range: Accommodates AWG 3/0 through 600 kcmil, matching the same wire sizes as the equivalent PowerPacT P circuit breaker lugs.
- Bolt-On, Plug-On Jaw Construction: Plugs onto the I-Line bus stack in the same manner as branch circuit breakers for a secure, code-compliant connection.
- Line Rated Current: Rated 1200-1200 A for sub-feed applications on I-Line panelboard systems.
- Series Compatibility: Engineered for the Square D PowerPacT P and I-Line product ranges, including HCR-U configurations.
- Mercury Free Construction: Manufactured without mercury for safer handling and disposal.
- Halogen-Free Plastic Parts: Plastic components meet halogen-free performance standards.
Certifications & Compliance
- UL Listed
- CSA Certified
- RoHS Eur Compliant with Exemptions
Technical Specifications
- Warranty: 18 months
- Take Back: No
- Tier: 2
- Returnability: Yes
- Warranty Period: 18 months
- Sustainable Packaging: No
- Mercury Free: Yes
- Packaging Without Single Use Plastic: No
- Tier Id: 2
- ROHS Eur In Scope: Yes
- Recycled Metal Content At Cr Level: 0 %
- Legacy WEEE Scope: In
- Packaging Made With Recycled Cardboard: Yes
- Serviceability: No
- With Recycled Cardboard: Yes
- WEEE Product Category: 4
- Without Single Use Plastic: No
- ROHS Exemption Information: Yes
- Traceability: No
- Relationshiptype: Compatible relationship
- China ROHS In Scope: No
- Scope Perimeter: Outside of Europe
- Return Indicator: Y
Typical Applications
- Industrial and Commercial Electrical Installations
- I-Line Panelboard and Switchboard Bus Systems
- Sub-Feed Lug Connections for PowerPacT P Circuit Breakers
- Panel Builder and OEM Control Panel Assemblies
- Contractor Distribution Equipment Upgrades
Why Square D?
Square D backs the PowerPacT P I-Line HCR-U sub-feed lug kit with UL Listing and CSA certification, mercury-free construction, and halogen-free plastic parts for dependable, code-compliant performance. Panel builders, OEMs, and contractors rely on this bolt-on plug-on jaw design to extend I-Line bus systems with the same fit and reliability as genuine PowerPacT P branch circuit breaker lugs.
Manufacturer Resources
Product Specs
- Product Type:
- Lug Kit
- Connection Type:
- Bolt-On
- Amperage Rating:
- 1200A
- Series:
- PowerPacT P
- Configuration:
- I-Line
- Listing:
- UL Listed
- Standards:
- UL-CSA
- Country Of Origin:
- United States
- Department:
- Electrical
- Product Group:
- Wire Connectors & Terminals
- Product Subgroup:
- Terminal Blocks & Strips
Square D S33930 – Frequently Asked Questions
1) What wire sizes does the Square D S33930 sub-feed lug kit accept?
The PowerPacT P I-Line HCR-U sub-feed lug kit takes conductors from AWG 3/0 up through 600 kcmil, the same wire range as the lugs on the equivalent PowerPacT P circuit breaker. If your sub-feed run is smaller than 3/0 or larger than 600 kcmil, this is the wrong kit for the termination.
2) How does an I-Line sub-feed lug kit mount into the panelboard?
It plugs on. The kit uses plug-on jaw construction and bolts onto the I-Line bus stack exactly the way a branch circuit breaker does, so no special bus modification is needed on Listed I-Line panelboard equipment. Connection type is bolt-on.
3) Will the Square D S33930 lug kit work in any panelboard, or only I-Line?
Only I-Line. The configuration is I-Line, and the kit is designed for use on Listed I-Line panelboard equipment, where it seats on the I-Line bus stack. A panelboard with a different bus arrangement will not accept it.
4) Is this Square D lug kit UL Listed and CSA certified for an inspected commercial install?
Yes. The sub-feed lug kit is UL Listed and CSA certified, with standards given as UL-CSA, and it is intended for Listed I-Line panelboard equipment. That covers the usual AHJ question on a commercial or industrial panel modification.
5) What is the current rating on this PowerPacT P sub-feed lug kit?
Line rated current is 1200 A. That is the ceiling for the sub-feed tap it terminates, so size the kit to the sub-feed breaker or feeder it is serving, not to the main bus rating of the panel.
6) What do I order to add a sub-feed tap to an existing I-Line panel instead of another breaker?
A sub-feed lug kit is the part. The Square D PowerPacT P I-Line HCR-U kit, model S33930, plugs onto the bus in a breaker space and gives you a lug termination rated 1200 A for AWG 3/0 to 600 kcmil conductors, so you feed a downstream panel directly rather than buying and landing a second breaker.
7) Is this lug kit mercury free and halogen free for a green building or hospital spec?
Both. The kit is built without mercury, and its plastic components meet halogen-free performance standards. It is also RoHS Eur compliant with exemptions, which is the line institutional procurement usually needs on the submittal.
8) Where is the Square D PowerPacT P sub-feed lug kit made?
Country of origin is the United States, which matters if you are procuring to a domestic-content requirement on a government or institutional project.
