Square D TeSys GV2 Combination Block, 3-Pole Motor Starter Connector

Square D TeSys GV2 Combination Block, 3-Pole Motor Starter Connector

(No reviews yet) Write a Review

Model: GV2AF4

In Stock (leaves warehouse same day if ordered before 3pm ET)

$4.87
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Square D TeSys GV2 Combination Block, 3-Pole Motor Starter Connector

The Square D TeSys GV2 combination block is a connection accessory for motor starter assemblies, engineered to link a GV2 motor circuit breaker or an LS1D32 fuse carrier to an LC1D09-D38 contactor. It is designed for assemblies that use an LAD311 mounting bracket and is built as a 3-pole connector within the TeSys Deca and TeSys GV2 range. This combination block is sold in lots of 10, making it a practical stocking item for panel builders and maintenance teams standardizing on Square D / Schneider Electric TeSys motor starter components.

Key Features

  • Motor Starter Connection: Combination block for the connection between a GV2 motor circuit breaker or LS1D32 fuse carrier and an LC1D09-D38 contactor.
  • Mounting Compatibility: Intended for use when the assembly incorporates an LAD311 mounting bracket.
  • 3-Pole Configuration: Poles description of 3P for standard three-phase motor starter assemblies.
  • Range Compatibility: Part of the TeSys Deca and TeSys GV2 product range, compatible with LC1D09...D38 contactors and adaptor plates.
  • Packaging: Sold in lots of 10, with a quantity per set of 10 units.
  • Manufacturer: Produced by Schneider Electric, country of origin Hungary.

Certifications & Compliance

  • RoHS EU Compliant (in scope, full compliance status)
  • Free of Substances of Very High Concern (SVHC) above the REACH threshold
  • Mercury Free
  • Toxic Heavy Metal Free
  • Sustainable, Recycled-Content Packaging Without Single-Use Plastic

Technical Specifications

  • Warranty: 18 months
  • Returnability: Yes
  • Poles Description: 3P
  • Toxic Heavy Metal Free: Yes
  • Mercury Free: Yes
  • Sustainable Packaging: Yes
  • Reach Free Of Svhc: Yes
  • ROHS Eur In Scope: Yes
  • Recycled Metal Content At Cr Level: 0 %
  • WEEE Product Category: 5
  • Serviceability: No

Typical Applications

  • Motor Starter Assemblies Using GV2 Motor Circuit Breakers
  • Fuse-Carrier (LS1D32) to Contactor Connections
  • LAD311 Mounting Bracket Assemblies
  • Combination Motor Starter Panels
  • Industrial Control Panel Construction and Maintenance
  • Commercial and Industrial Electrical Installations

Why Square D?

Square D TeSys components, manufactured by Schneider Electric, are built for reliable, code-compliant performance in demanding industrial motor control applications. This combination block reflects that standard with mercury-free, toxic-heavy-metal-free construction and RoHS/REACH-compliant materials, giving electrical professionals a dependable connection accessory for TeSys GV2 and TeSys Deca motor starter assemblies.

Manufacturer Resources

Product Specs

Product Type:
Motor Starter Accessory
Series:
TeSys GV2
Configuration:
3-Pole
Department:
Electrical
Product Group:
Motor Control & Automation
Product Subgroup:
Motor Starters & Contactors

Square D GV2AF4 – Frequently Asked Questions

1) Will the GV2AF4 work with my contactor if it is larger than an LC1D38?
No. The GV2AF4 block is specified for LC1D09 through LC1D38 contactors only. Above that frame size the terminal spacing and current rating no longer match, so a larger contactor needs the connection accessory for its own frame rather than this block.
2) Do I need an LAD311 bracket to use the GV2AF4 combination block?
The block is intended for assemblies that incorporate an LAD311 mounting bracket, which is what holds the breaker and contactor at the fixed spacing the block spans. If your panel layout does not use that bracket, the pole centers will not line up and the block is the wrong accessory.
3) What is the equivalent connecting link if my starter is ABB instead of Square D?
The GV2AF4 only fits the Square D / Schneider TeSys line (GV2 breaker or LS1D32 fuse carrier to LC1D09-D38 contactor). For an ABB assembly, the ABB BEA series insulated 3-pole connecting link for AF09-16 contactors with MS116 or MS132 manual motor starters is the counterpart part. These links are frame-specific and do not cross between brands.
4) What is the ABB equivalent of the Square D GV2AF4 combination block?
The closest ABB counterpart is the ABB BEA16-4 insulated 3-pole connecting link, which joins an AF09-16 contactor to an MS116 or MS132 manual motor starter. The GV2AF4 is the Schneider Electric version of that same idea: a 3-pole connector that links a GV2 motor circuit breaker or LS1D32 fuse carrier to an LC1D09-D38 contactor. Both are brand-locked - the BEA16-4 is built around ABB's AF/MS pairing and the GV2AF4 around the TeSys GV2 and TeSys Deca pairing, so they are not interchangeable within the same assembly.
5) Is the GV2AF4 sold individually or in a pack?
It ships in lots of 10, with a quantity per set of 10 units. That suits panel builders and maintenance shops stocking TeSys starter components, but if you only need one block for a single repair you are still buying the full set of ten.
6) Does the Square D GV2AF4 meet RoHS and REACH requirements for our facility spec?
The block is RoHS EU compliant and in scope, free of REACH substances of very high concern above threshold, mercury free and free of toxic heavy metals. It ships in recycled-content packaging without single-use plastic, and it falls under WEEE product category 5.
7) Can I use an Eaton Freedom mounting plate instead of the GV2AF4?
No - they do different jobs. The Eaton C321CMP0 is a NEMA Size 00 mounting plate for Freedom series devices, so it supports a starter mechanically. The GV2AF4 is a 3-pole electrical connection block that carries the power connection between a GV2 breaker or LS1D32 fuse carrier and an LC1D09-D38 contactor. In a TeSys assembly the mounting role is handled by the LAD311 bracket, and the GV2AF4 is what makes the pole-to-pole connection.
8) What should I order if I need an operating accessory rather than a power connection block for a manual motor starter?
For an operating or actuation accessory, the ABB MSMN coded driver for MS series manual motor starters is that type of part. The Square D GV2AF4 is not an actuator - it is a 3-pole combination block that makes the power connection between a GV2 motor circuit breaker or LS1D32 fuse carrier and an LC1D09-D38 contactor. If the panel needs both, they are separate line items and each is tied to its own brand's starter family.
9) Can I use the GV2AF4 on a single-phase motor starter?
It is built as a 3P connector for three-phase assemblies. On a single-phase starter you would only be using two of the three poles, so check your panel drawing before specifying it; for standard three-phase motor branch circuits it is the matching part.
10) Is the GV2AF4 a serviceable part or replace-only?
Replace-only. Serviceability is listed as no, so a damaged or burned block gets swapped out rather than repaired. Panel shops that keep a GV2 starter line running typically hold the lot of 10 on the shelf for that reason.
11) Is the Square D GV2AF4 a renewal part like the Eaton 9-1945?
No. The Eaton 9-1945 is a Size 00 Series A1 renewal part for contactors and starters rated 480V - a replacement component for a device already in service. The GV2AF4 is an assembly accessory, a 3-pole combination block ordered when building or reconfiguring a TeSys GV2 starter so the breaker or LS1D32 fuse carrier ties to the LC1D09-D38 contactor. It is also sold in lots of 10, which suits panel builders stocking the part rather than one-off repairs.
12) Where is the Square D GV2AF4 made?
Country of origin is Hungary, manufactured by Schneider Electric. That matters on public and institutional jobs where origin has to be documented on the submittal.
