Command Access MD-ALRP Electrified Rim Exit Device with Latch Pullback - 12/24V Adams Rite 8800 Series Retrofit

Command Access MD-ALRP Electrified Rim Exit Device with Latch Pullback - 12/24V Adams Rite 8800 Series Retrofit

(No reviews yet) Write a Review

Model: CAT MD-ALRP-62-24-36-AD-1
From the 8800 series Collection
$583.47
Selected Finishes is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$583.47
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Command Access Electrified Rim Exit Device with Latch Pullback - 12/24V Adams Rite 8800 Series Retrofit

Professional Electrified Exit Device Solution for Storefront Applications

The Command Access electrified latch pullback modification transforms the Adams Rite 8800 Rim storefront exit device into a reliable, centrally-controlled access solution. Operating on 12 or 24 VAC/DC with low current draw (900mA @ 12V, 450mA @ 24V), this retrofit modification enables extended wire runs up to 1500' with 12ga wire while maintaining the device's slim profile that projects less than 3" from the door face. UL Listed for professional applications with satin aluminum finish and factory dogging capability.

Professional Features & Benefits

  • Flexible Power Options: 12 or 24 VAC/DC operation with low current draw (900mA @ 12V, 450mA @ 24V) for efficient centralized power supply integration.
  • Extended Wire Run Capability: Supports wire runs up to 1500' with 12ga wire, 1250' with 14ga wire, 1000' with 16ga wire, and 700' with 18ga wire for flexible installation options.
  • Compact Storefront Design: Slim profile projects less than 3" from door face, ideal for narrow-style storefront doors while maintaining full functionality.
  • Seamless Retrofit Installation: Compatible with Adams Rite 8800 Rim Series devices, retrofits into existing mounting locations without door removal for convenient upgrades.
  • Continuous Duty Operation: Extended latch pullback capability designed for "continuously on" operation under demanding commercial use.
  • Factory Dogging Maintained: Preserves original mechanical dogging functionality for manual override capability when needed.
  • Ready-to-Install Package: Includes six-foot power cable with quick connect for simplified field wiring and installation.
  • Manufacturer Warranty: 3-Year "No Hassle" Limited Warranty for added confidence and protection.

Technical Specifications

  • Application: Storefront
  • Collection: 8800 series
  • Department: Door Hardware
  • Device Type: Rim Exit Device
  • Grade: UL Listed
  • Product Category: Exit Devices and Trim
  • Product Function: Latch Pullback
  • Product Group: Exit Devices and Trim
  • Product Subgroup: Motorized & Electrified Exit Devices
  • Series: Adams Rite 8800
  • Subcategory: Exit Device Trim

Professional Applications

  • Commercial Storefront Security Systems
  • Retail Access Control Integration
  • Office Building Entry Management
  • Educational Facility Safety Systems
  • Healthcare Facility Access Control
  • Multi-Tenant Commercial Properties
  • Government and Municipal Buildings

Why Choose Command Access Quality?

Command Access electrified exit devices deliver professional-grade reliability with UL Listed certification and low current draw design optimized for centralized power systems. The 3-Year "No Hassle" Limited Warranty and retrofit compatibility with existing Adams Rite 8800 installations provide exceptional value. Engineered for demanding commercial storefront applications where dependable continuous duty performance and flexible installation options are essential.

Manufacturer Resources

Command Access Catalog

Product Specs

Product Group:
Exit Devices and Trim
Series:
Adams Rite 8800
Collection:
8800 series
Application:
Storefront
Subcategory:
Exit Device Trim
Product Subgroup:
Motorized & Electrified Exit Devices
Grade:
UL Listed
Device Type:
Rim Exit Device
Product Function:
Latch Pullback
Product Category:
Exit Devices and Trim
Department:
Door Hardware

Command Access CAT MD-ALRP-62-24-36-AD-1 – Frequently Asked Questions

1) Will the Command Access MD-ALRP work on my existing Adams Rite 8800 storefront door without pulling the door?
The MD-ALRP is a latch pullback modification built for Adams Rite 8800 Rim series exit devices, and it retrofits into the existing mounting locations, so the door stays hung. Order it matched to the device you actually have: the compatibility choice is either the Adams Rite 8801 or the 8802 rim device. Check the model stamped on the device before you order, because those are two different orderable configurations.
2) Do I order the 12V or the 24V version of the Command Access electrified rim exit device?
Both are offered, so it comes down to the power supply already feeding the opening. At 12 VAC/DC the latch pullback draws 900mA; at 24 VAC/DC it draws 450mA. If you are running several openings off one centralized supply, 24V halves the per-device draw and gives you more headroom on the same supply. If the access control panel at that door is already putting out 12V, take the 12V. Every device length is available in both voltages.
3) How far can I run wire to a Command Access latch pullback exit device from the power supply?
Run length depends on the gauge you pull: up to 1500 feet with 12ga, 1250 feet with 14ga, 1000 feet with 16ga, and 700 feet with 18ga. That is what makes this workable when the power supply lives in an electrical room at the far end of the building rather than above the door. A six-foot power cable with a quick connect comes with the modification for the door-side termination.
4) What door widths does the Adams Rite 8800 electrified latch pullback device cover?
Three device lengths are offered: 36, 42, and 48. Match the length to the device already on the opening, since this is a modification of the 8800 rim device rather than a universal kit. All three lengths come in both 12V and 24V and in both finishes.
5) Will an electrified exit device fit a narrow stile aluminum storefront door?
That is exactly the application this one is built for. It is a rim device for storefront openings, and the profile projects less than 3 inches from the door face, so it clears the frame and the closer arm on narrow-style aluminum doors where a wide-body device would not sit. Because it is a rim device it latches at the strike on the jamb or a mullion, not at the head and threshold.
6) Does electrifying the Adams Rite 8800 kill the mechanical dogging?
No. The latch pullback modification keeps the original factory dogging, so you can still dog the device down mechanically to hold the opening in push/pull during business hours or as a manual override if the power supply drops.
7) Can this electrified latch retraction device stay energized all day for a retail storefront?
Yes, the extended latch pullback is rated for continuously on operation, which is what a retail or office storefront needs when the door is unlocked for the whole business day. That is also why the current draw matters: at 450mA on 24V it will sit energized on a centralized supply without cooking the supply's capacity.
8) What is the difference between latch pullback and an electric strike for controlling a storefront entrance?
Latch pullback electrifies the exit device itself, holding the latch retracted so the door pushes and pulls freely from both sides. An electric strike releases from the frame side instead, which means the door is still latched and only unlocks for entry. Pullback is the choice when you want the entrance to sit in true push/pull during open hours; a strike is the choice when you only need momentary release on a credential and want to leave the device alone. This modification is the pullback approach, applied to an Adams Rite 8800 rim device.
9) What finishes does the Command Access MD-ALRP electrified exit device come in?
Two finishes: 628/US28 satin aluminum, which is the standard match for clear anodized aluminum storefront, and 313/US10B oil rubbed bronze for dark bronze anodized frames. Both are available across all three lengths and both voltages, so you can standardize a run of entrances on one finish regardless of door width.
