Command Access PD25-36 Rim Exit Device, PD25 Retrofit Kit for Von Duprin 98/99 & Cal Royal 7700 — Escutcheon Trim, Motorized Latch Pullback with Electric Dogging
The Command Access PD25 series is a motorized latch pullback Grade 1 architectural exit device; made for use in all institutions and commercial buildings when heavy duty, fire and life safety operation is required. The PD25 easily converts an existing Von Duprin 98/99 series device installation to a Command Access latch pullback application.
Specification
-
MM5 Module Updated Specifications
-
Voltage Range: 24 VDC ± 10%
-
System Protection: Unit shuts down if voltage exceeds 28 VDC
-
Standard Mode:
-
Average Current Peak: 900 mA
-
Average Current Hold: 215 mA
-
-
High Torque Mode:
-
Average Current Peak: 2 A
-
Average Current Hold: 250 mA
-
-
PTS (Post-Travel Stop) Adjustment: Approx. 1/4″
Accessories
-
Request-to-Exit Switch – Factory installed
-
Latchbolt Monitor Switch – Factory installed
-
Request-to-Exit Kit (PD25REXKIT-ED) – Field installable
Features
-
MM5 Smart Module with onboard diagnostics and audible feedback for adjustment and power issues
-
PTS: 5-second electronic adjustment for simple post-installation fine-tuning
-
Electric Dogging rated for continuous duty, with automatic re-engagement if push pad is pulled from dogged position
-
Low Current Draw with field-switchable “High Torque” mode for added flexibility
-
Supports up to 300′ wire runs with 2-18ga wire, allowing installers to place the power supply in a centralized location (e.g., same closet as access control panel)
-
8′ Cable with Quick Connect for easy connection between MM5 module and power supply lead
-
Optional Request-to-Exit can be added for expanded functionality
-
Covered by a 3-Year “No Hassle” Warranty
Manufacturer Resources
Product Specs
- Product Group:
- Electronic Access Controls
- Series:
- PD Series
- Product Subgroup:
- Electronic Exit Device/Trim
- Subcategory:
- Exit Device Trim
- Commercial/Residential:
- Commercial
- Product Type:
- Exit Device Trim
- Warranty:
- 3 Year Warranty
- Product Attribute:
- Electric Dogging
- Product Function:
- Fail Secure EU Motorized
- Product Voltage:
- 24 to 30 VDC
- Product Category:
- Electronic Access Controls
