Eaton Four-Pole Auxiliary Cont...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$79.71
Eaton Four-Pole Auxiliary Contact Contactor Accessory, D-G Frame

Eaton Four-Pole Auxiliary Contact Contactor Accessory, D-G Frame

(No reviews yet) Write a Review

Model: XTCEXFBG31

In Stock (leaves warehouse same day if ordered before 3pm ET)

$79.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Four-Pole Auxiliary Contact Contactor Accessory, D-G Frame

The Eaton Four-Pole Auxiliary Contact Contactor Accessory is a purpose-built control component designed for use with Eaton's XTRE control relays. Configured with a 3NO-1NC contact arrangement and screw terminals, this accessory carries a 16A conventional thermal current rating and is sized for D-G frame equipment. Front-mounting for accessible installation, it is certified to IEC 60947 and built to extend auxiliary switching capability on Eaton motor control and protection systems used in commercial and industrial control panels.

Key Features

  • Four-Pole Configuration: Provides four-pole auxiliary contact switching for expanded control circuit capability on compatible Eaton control relays.
  • 3NO-1NC Contact Configuration: Delivers three normally-open and one normally-closed contact arrangement for flexible control wiring schemes.
  • Screw Terminals: Features secure screw-terminal connections for straightforward, reliable field wiring.
  • 16A Conventional Thermal Current: Rated at 16A conventional thermal current for dependable auxiliary contact performance under continuous duty.
  • D-G Frame Size: Sized specifically for D-G frame Eaton control relays and contactors for direct mechanical compatibility.
  • Front Mounting: Mounts to the front of the compatible XTRE control relay for easy access and simplified installation.
  • Used with XTRE Control Relays: Purpose-engineered accessory for Eaton's XTRE control relay platform, extending its auxiliary switching functions.

Certifications & Compliance

  • IEC 60947 Certified

Technical Specifications

  • Quantity: 5
  • Conventional thermal current: 16A
  • Warranty: Not Applicable
  • Frame size: D-G

Typical Applications

  • Motor Control Centers and Industrial Control Panels
  • Industrial Automation and Machine Control Systems
  • Contactor and Control Relay Auxiliary Switching Circuits
  • Motor Control and Motor Protection Assemblies
  • Panelboard and Switchgear Auxiliary Wiring

Why Eaton?

Eaton engineers its motor control and protection components for the demands of industrial control environments, and this auxiliary contact accessory is no exception. With IEC 60947 certification, secure screw-terminal wiring, and a defined 16A conventional thermal current rating, it extends the functionality of XTRE control relays with the code-compliant reliability electrical professionals expect from Eaton's motor control and protection product line.

Manufacturer Resources

Product Specs

Number Of Poles:
Four-pole
Used with:
XTRE control relays
Item Quantity:
5
Terminals:
Screw
Conventional thermal current:
16A
Product Type:
Auxiliary Contact
Warranty:
Not Applicable
Mounting Method:
Front
Frame size:
D-G
Certifications:
IEC 60947
Department:
Electrical
Configuration:
Four-Pole
Connection Type:
Screw Terminals
Amperage Rating:
16A
Standards:
IEC 60947
Product Group:
Motor Control & Automation
Product Subgroup:
Motor Starters & Contactors

Eaton XTCEXFBG31 – Frequently Asked Questions

1) Will the Eaton XTCEXFBG auxiliary contact block fit my contactor, or is it only for XTRE relays?
The XTCEXFBG front-mount auxiliary block is specified for use with Eaton XTRE control relays and is sized for D-G frame equipment. If your device is not an Eaton XTRE relay in the D-G frame range, this is not the block to order. Frame size is the thing to confirm first, since the mechanical fit is frame-specific.
2) What is the difference between the XTCEXFBG31 and XTCEXFBG40 auxiliary contacts?
Both are four-pole front-mount blocks; the difference is the contact arrangement. XTCEXFBG31 gives you three normally open and one normally closed contact. XTCEXFBG40 gives you four normally open and no normally closed. Order the 31 if your control scheme needs an NC contact for interlocking or a stop path, the 40 if every contact is doing a permissive or status function.
3) I need an auxiliary contact but my gear is not Eaton. What else is available?
Auxiliary contacts are brand and frame specific, so match the block to the device. For ABB contactors and relays there is the ABB CR305X Series auxiliary contact, and for ABB OT/OS disconnect switches the OA1G10 1-NO auxiliary contact switch. Square D users have the Type S isolated alarm contact kit and, for ComPact NSXm breakers, the LV426950 OF/SD status contact. Bussmann's BAC Series covers auxiliary contact needs in the 1A to 12A range. The Eaton XTCEXFBG only suits Eaton XTRE relays in D-G frame.
4) I need breaker status indication, not contactor auxiliary contacts - what should I order instead of the Eaton XTCEXFBG?
For molded case breaker status, the Square D ComPact NSXm auxiliary contact provides OF/SD circuit breaker status signaling, and the Square D Type S isolated alarm contact kit provides an alarm contact for Type S devices. The Eaton XTCEXFBG is a contactor accessory that front-mounts to D-G frame XTRE control relays to add auxiliary switching, so it will not report breaker trip or position.
5) What is the closest alternative to the Eaton XTCEXFBG four-pole auxiliary contact if the panel uses ABB contactors instead of Eaton?
The Eaton XTCEXFBG is a front-mounting four-pole auxiliary contact sized for D-G frame equipment and built for Eaton XTRE control relays, so it is not a fit on an ABB starter. For ABB contactors and relays, the ABB CR305X Series auxiliary contact is the counterpart product. Auxiliary contacts are frame-specific, so match the block to the contactor family in the panel rather than to the contact count alone.
6) How many auxiliary contacts come in a pack of the Eaton XTCEXFBG?
Item quantity is 5, so you are buying a five-piece group rather than a single block. Worth knowing before you spec it for a one-off panel repair, and useful if you are standardizing several starters in the same lineup.
7) What current can this Eaton auxiliary contact block carry in a control circuit?
The block is rated 16A conventional thermal current. That is the continuous carry rating for the contacts, and it comfortably covers typical PLC inputs, pilot lights, and coil circuits in a motor control panel. It is an auxiliary contact, not a power pole, so it is not intended to switch motor load.
8) Does the Eaton XTCEXFBG auxiliary contact meet IEC 60947?
IEC 60947 is the stated standard for this auxiliary contact block, which is the low-voltage switchgear and controlgear series that panel builders working to IEC practice specify against.
9) How does the Bussmann BAC auxiliary contact differ from the Eaton XTCEXFBG?
The Bussmann BAC Series auxiliary contact is specified over a 1A to 12A amp range, while the Eaton XTCEXFBG carries a 16A conventional thermal current rating with screw terminals and is certified to IEC 60947. The Eaton unit is a four-pole block for D-G frame XTRE control relays; the Bussmann BAC is a Bussmann-platform contact. Confirm the host device family before substituting either way.
10) What kind of wire terminations does this auxiliary contact use?
Screw terminals, so field wiring lands directly with a screwdriver and no crimped push-in adapters or tooling are needed. Mounting is to the front of the relay, which keeps those terminals reachable after the block is installed and while the panel is live-labeled for troubleshooting.
11) If I only need one normally closed contact, is there a simpler option than the Eaton XTCEXFBG four-pole block?
Within the Eaton XTCEXFBG family the choice is between the 3NO-1NC arrangement, which gives you that single normally closed contact plus three spares, and the 4NO-0NC arrangement. If the requirement is a single contact on a disconnect rather than a contactor, the ABB OA1G10 is a 1-NO auxiliary contact switch for OT/OS disconnects. On an Eaton D-G frame XTRE relay, the 3NO-1NC four-pole block is the arrangement that carries the NC contact.
