Corbin Russwin 438F90 - ML2000 Key Plate Packet

Corbin Russwin 438F90 Grade 1 - ML2000 Key Plate Packet

(No reviews yet) Write a Review

Model: 438F90-626
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$41.83
$30.06
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Corbin Russwin 438F90 ML2000 Series Cast Escutcheon Key Plate Packet for Mortise Locks

Precision-Fit Replacement Key Plate Packet for ML2000 and ML2000HS Mortise Lock Series

The Corbin Russwin 438F90 is a Cast "V" Escutcheon Key Plate Packet engineered specifically for use with the ML2000 and ML2000HS Mortise Lock Series. Designed as a standard component for privacy function with emergency release only, this sectional trim part features a key plate with a 1-3/8" (35mm) diameter plate size. Constructed from cast brass or bronze, this packet delivers the precision fit and durable material quality expected from Corbin Russwin commercial door hardware. Each packet includes one Key Plate and two #6 x 1/2" Oval Truss Head Screws for complete, ready-to-install convenience.

Professional Features & Benefits

  • ANSI/BHMA Grade 1 mortise lock per A156.13 Series 1000, Operational and Security Grade 1
  • UL Cycle above and beyond: 14.5 Million Cycles (Verification ID: V875753)
  • Patented Quick Reversible latchbolt — reverse handing without disassembling the lock case
  • Multi-function capability: 12 functions configurable from one ML2054 lockbody
  • Heavy-gauge steel lockcase 5-7/8" x 4" x 15/16"; 1" stainless steel deadbolt, 1" throw
  • 3/4" (19mm) throw anti-friction two-piece latchbolt requires less force to close
  • Wide variety of trim designs including Muséo®, Vineyard™, Behavioral Health (BHSS/BLSS)
  • Status indicator options for locked/unlocked visibility (sectional and escutcheon trim)
  • Motorized Electric Latch Retraction (MELR) available for ML20900 series
  • Thru-bolted trim designs for proper alignment and increased security
  • Can be used with new or existing Corbin Russwin key systems; accepts most other manufacturers' cylinders
  • UL/cUL listed, UL10C positive pressure; 3-hour fire door up to 4' x 10' single or 8' x 10' pair
  • Ten-year mechanical warranty; five-year MELR; two-year electrical

Technical Specifications

  • Grade: ANSI/BHMA A156.13 Series 1000, Operational and Security Grade 1
  • Handing: Handed; quick reversible — re-handed without disassembling the lock case
  • Door Thickness: 1-3/4" (44mm) standard; optional thicknesses available
  • Backset: 2-3/4" (70mm)
  • Lockcase: Heavy-gauge steel, 5-7/8" (149mm) x 4" (102mm) x 15/16" (24mm)
  • Armored Front: Wrought brass, bronze, or stainless steel, 8" x 1-1/4"
  • Latchbolt: 2-piece mechanical with anti-friction insert, 5/8" x 1" x 3/4" (19mm) throw
  • Auxiliary Latchbolt: 9/16" (14mm) effective throw; deadlocking
  • Deadbolt: One-piece stainless steel, 19/32" x 1-1/4" x 1" (25mm) throw
  • Strike: Wrought brass, bronze, or stainless steel, ANSI straight lip, 4-7/8" x 1-1/4" x 1-1/8" lip to center
  • Cylinder: Brass, 6-pin L4 keyway, 0-bitted standard
  • Spacing: C. to c. knob/lever to cylinder: 3-5/8" (92mm); knob/lever to thumbturn: 2-7/16" (62mm)
  • Certifications: ANSI/BHMA A156.13 Grade 1; UL/cUL UL10C 3-hour positive pressure; ADA A117.1; California State Fire Marshal; Windstorm/Hurricane certified
  • Warranty: Ten-year mechanical; five-year MELR; two-year electrical

Professional Applications

  • Commercial Office Buildings
  • Healthcare Institutions
  • Educational Facilities
  • Retail Establishments
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Choose Corbin Russwin Quality?

Corbin Russwin door hardware parts and accessories are manufactured to exacting commercial standards, with this key plate packet crafted from cast brass or bronze to ensure lasting performance and precise fitment within the ML2000 and ML2000HS Mortise Lock Series. As a commercial-grade component classified under Mechanical Locks, it is engineered to meet the demands of high-use environments where reliable, properly fitted hardware is essential. Trust Corbin Russwin to deliver the quality and compatibility required for professional door hardware installations.

Product Specs

Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Keyplates
Commercial/Residential:
Commercial
Subcategory:
Parts and Accessories
Product Attribute:
Parts and Accessories
Product Model:
438F90
Product Category:
Mechanical Locks
Department:
Door Hardware

Corbin Russwin 438F90-626 – Frequently Asked Questions

1) Is the 438F90 for a privacy lock or a keyed lock?
It is the standard plate for privacy function with emergency release only. On that function the opening in the plate takes the emergency release, not a full keyed cylinder. If the door uses a keyed function, you need the plate specified for that function instead.
2) What finishes does the Corbin Russwin 438F90 key plate come in?
Eight finishes: 606 satin brass, 612 satin bronze, 613 satin bronze oil-rubbed, 619 satin nickel, 625 bright chrome, 626 satin chrome, 630 satin stainless steel, and BSP black suede powder coat. Order to match the rest of the trim on the opening, since a replacement plate sits directly beside the existing lever rose.
3) Does replacing the key plate on an ML2000 affect the fire rating on the door?
The ML2000 mortise lock is UL/cUL listed to UL10C positive pressure and rated for 3-hour fire doors up to 4 ft x 10 ft single or 8 ft x 10 ft pair. Using the manufacturer's own trim parts, like the 438F90 plate and its supplied screws, is how you keep that assembly as listed. Substituting a non-Corbin plate on a rated door is where inspections go wrong.
4) Does the key plate have to match the handing of the door?
No. The plate is a round 1-3/8 inch cast trim piece and installs either hand. Handing on the ML2000 is a function of the lockbody, which uses a quick reversible latchbolt that re-hands without opening the lock case.
5) Where does the key plate sit relative to the lever on an ML2000 sectional trim?
On ML2000 sectional trim the center-to-center spacing from knob or lever to cylinder is 3-5/8 inches (92mm), and lever to thumbturn is 2-7/16 inches (62mm). That is the hole pattern already in your door, so the replacement plate drops onto the existing prep with no new boring.
6) I manage a building standardized on Corbin Russwin ML2000 mortise locks. Can I stock this plate as a repair part across all of them?
Yes, for privacy-function openings with cast "V" sectional escutcheon trim. The ML2000 is ANSI/BHMA A156.13 Series 1000 Grade 1 operational and security, so it is the typical building standard for restrooms and similar privacy doors. Stock the plate in the finish your doors already carry and keep the two supplied screws with it.
7) What is the 438F90 key plate made of?
Cast brass or bronze, plated or coated to the finish you order. Cast trim is what the ML2000 sectional program uses on commercial openings rather than stamped plate.
8) Does the 438F90 work on a thicker-than-standard door?
Door thickness is handled by the lockbody and spindle, not the plate. Standard ML2000 setup is a 1-3/4 inch (44mm) door with optional thicknesses available, and the plate itself is surface trim that mounts with the two #6 x 1/2 inch screws regardless.
