Corbin Russwin CLX3300 Grade 1 Mechanical Functions Tailpiece, Corbin Russwin & Yale Fixed Core Cylinder Tailpiece Pack, 1-3/8in - 2in Door

Corbin Russwin CLX3300 Grade 1 Mechanical Functions Tailpiece, Corbin Russwin & Yale Fixed Core Cylinder Tailpiece Pack, 1-3/8in - 2in Door

(No reviews yet) Write a Review

Model: 862F998

In Stock (leaves warehouse same day if ordered before 3pm ET)

$39.68
$32.73
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Corbin Russwin 62F998 CLX3300 Mechanical Functions Fixed Core Cylinder Tailpiece Pack for 1-3/8" - 2" Doors

Professional Fixed Core Cylinder Tailpiece Solution for CLX3300 Series Locksets

The Corbin Russwin 62F998 CLX3300 Mechanical Functions Fixed Core Cylinder Tailpiece Pack is a commercial-grade accessory engineered for use with Corbin Russwin and Yale fixed core cylinder systems. This tailpiece pack is compatible with doors ranging from 1-3/8" to 2" in thickness and is available in both 6-pin and 7-pin configurations to accommodate a variety of keying requirements. Manufactured under the ASSA ABLOY Accentra platform, this component ensures reliable mechanical function integration within the CLX3300 Series cylindrical lever lockset family.

Professional Features & Benefits

  • ANSI/BHMA Grade 1 cylindrical lock per A156.2 (2022) Series 4000
  • UL Cycle above and beyond: 20 Million Cycles (Verification ID: V875753)
  • Exceeds 3,100 in-lb abusive locked lever torque — 2.6× ANSI requirements
  • Exceeds 1,600 lbs offset lever pull — 8× ANSI requirements
  • Innovative Lever Release™ freewheeling design for vandal resistance
  • Lock chassis design supports all cylinder formats (fixed core to interchangeable core)
  • Patented adjustable push/turn button for easy door thickness adjustment
  • Available with BHSS behavioral health trim and VSL visual status indicators
  • EcoFlex® technology on CLX33900: up to 92% energy reduction (GreenCircle certified)
  • Available with 27 mechanical and 2 electrified functions
  • CLX3352 Classroom Intruder: locking from either side, always-free egress
  • ElectroLynx® 8-pin molex connector on electrified units
  • Ten-year limited mechanical warranty (two-year limited electrical)

Technical Specifications

  • Grade: ANSI/BHMA A156.2 (2022) Series 4000, Grade 1
  • Door Prep: ANSI/SDI A250.14
  • Handing: Non-handed
  • Door Thickness: 1-3/4" 2" (44–51mm) standard; optional 1-3/8" (D138) or over 2" up to 2-1/4" (D214)
  • Backset: 2-3/4" (70mm) standard; optional 2-3/8", 3-3/4", 5"
  • Minimum Stile: 4-1/2" (114mm)
  • Latchbolt: Stainless steel, 1/2" (13mm) throw; optional 3/4" (19mm) deadlocking fire latch
  • Front: Wrought brass, bronze, or stainless steel, 2-1/4" x 1-1/8" standard
  • Strike: Wrought brass or stainless steel, ANSI curved lip, 4-7/8" x 1-1/4" x 1-1/4" lip to center
  • Cylinder: Brass, 6-pin L4 keyway, 0-bitted standard
  • Electrified Voltage: 12VDC or 24VDC; range 10.2–26.4VDC (CLX33900)
  • Electrified Current: 10mA continuous; 500mA peak @ 12VDC or 24VDC
  • Operating Temperature: -13°F (-25°C) to 151°F (66°C) (electrified)
  • Certifications: ANSI/BHMA A156.2 Grade 1; UL/cUL 3-hour; UL294 (electrified); NFPA 80; ADA A117.1; Windstorm/Hurricane certified
  • Warranty: Ten-year limited mechanical; two-year limited electrical

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Retail Establishments
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Choose Corbin Russwin Quality?

Corbin Russwin parts and accessories deliver professional-grade reliability as genuine OEM components engineered to exact specifications for the CLX3300 Series cylindrical lever lockset platform. This fixed core cylinder tailpiece pack, available in 6-pin and 7-pin configurations, is built to maintain the mechanical integrity of Corbin Russwin and Yale fixed core cylinder systems across doors from 1-3/8" to 2" thick. Engineered for demanding commercial applications where dependable performance and precise fit are essential.

Product Specs

Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Tailpiece
Commercial/Residential:
Commercial
Subcategory:
Parts and Accessories
Product Attribute:
Parts and Accessories
Product Model:
862F998
Product Size:
1-3/8"
Product Category:
Mechanical Locks
Department:
Door Hardware

Corbin Russwin 862F998 – Frequently Asked Questions

1) What does the Corbin Russwin 62F998 tailpiece pack actually do, and when do I need it?
It is the tailpiece hardware that links a fixed core cylinder to the lock chassis on Corbin Russwin CLX3300 Series cylindrical lever locksets. You order it when you are fitting or re-fitting a fixed core (non-interchangeable-core) cylinder and need the correct tailpiece length for the door thickness. It is not a cylinder and not a lock, just the drive part between them.
2) Do I order the 6-pin or the 7-pin tailpiece pack?
Match it to the cylinder you are installing. The pack comes in 6-pin and 7-pin versions, so if your keying system uses 7-pin fixed core cylinders take the 7-pin; standard CLX3300 cylinders ship 6-pin with an L4 keyway, 0-bitted, which is the 6-pin pack.
3) Will this tailpiece work on a 1-3/8 inch door?
Yes. The pack covers door thicknesses from 1-3/8 inch up to 2 inch. On the CLX3300 the standard door range is 1-3/4 to 2 inch (44-51mm), with 1-3/8 inch handled by the D138 option, so the pack spans both. Doors over 2 inch use the D214 option up to 2-1/4 inch.
4) Does this tailpiece fit Yale cylinders too, or only Corbin Russwin?
Both. The pack is made for Corbin Russwin and Yale fixed core cylinder systems, which share the ASSA ABLOY Accentra platform.
5) Can I use this if my CLX3300 locks have interchangeable core cylinders?
No. This pack is the fixed core tailpiece. The CLX3300 chassis accepts every cylinder format from fixed core through interchangeable core, but the tailpiece is specific to the format, so an IC core installation needs the tailpiece for that core type rather than this one.
6) I'm standardizing lever locks across a school. Does swapping cylinders and tailpieces affect the lock's Grade 1 rating or fire listing?
Using the genuine OEM tailpiece keeps the assembly as specified. The CLX3300 cylindrical lever lockset is ANSI/BHMA A156.2 (2022) Series 4000 Grade 1, UL/cUL 3-hour fire rated, meets NFPA 80 and ADA A117.1, and is windstorm/hurricane certified. Substituting non-OEM drive parts is what puts that spec at risk.
7) Do I have to re-drill the door to change door thickness on a CLX3300?
No. Door prep follows ANSI/SDI A250.14, and the lock uses a patented adjustable push/turn button so thickness is set by adjustment rather than new prep. Backset stays as prepped, 2-3/4 inch (70mm) standard with 2-3/8, 3-3/4 and 5 inch options, and minimum stile is 4-1/2 inch (114mm).
8) Is handing something I need to specify with this tailpiece?
No. The CLX3300 cylindrical lever lockset is non-handed, so the tailpiece pack is ordered by pin count and door thickness only.
9) Will the existing strike still work after I service the cylinder on these locks?
Yes, the tailpiece has nothing to do with latching. The CLX3300 latchbolt is stainless steel with a 1/2 inch (13mm) throw, or 3/4 inch (19mm) on the optional deadlocking fire latch, into an ANSI curved lip strike measuring 4-7/8 x 1-1/4 inches with 1-1/4 inch lip to center. Front is 2-1/4 x 1-1/8 inches standard.
10) Is the 62F998 tailpiece pack usable on the electrified CLX33900 locks as well?
The pack serves the CLX3300 mechanical functions with fixed core cylinders. The CLX33900 electrified units run 12VDC or 24VDC (10.2-26.4VDC range) with an ElectroLynx 8-pin molex connector, and the cylinder side is still mechanical, but for an electrified opening confirm the function you are ordering is a mechanical-function cylinder application before using this pack.
