Corbin Russwin ML2050 Grade 1 Mortise Half Dummy Trim

Corbin Russwin ML2050 Mortise Half Dummy Trim Grade 1, Field Reversible, 1-3/4" Door Thickness

Commercial-Grade Mortise Dummy Trim for High-Traffic Applications

The Corbin Russwin ML2050 is a Grade 1 mortise half dummy trim from the ML2000 Series, engineered for demanding commercial, institutional, industrial, and government environments. Grips act as pulls only with no locking operation, making this trim ideal for applications where a consistent aesthetic is required without active hardware function. Designed for a standard door thickness of 1-3/4" (44mm) and featuring field-reversible handing, the ML2050 integrates seamlessly into the full ML2000 Series ecosystem. Constructed with brass or bronze substrate, this trim delivers the durability and design continuity expected in high-use facilities such as offices, schools, hospitals, and hotels.

Professional Features & Benefits

• ANSI/BHMA Grade 1 mortise lock per A156.13 Series 1000, Operational and Security Grade 1
• UL Cycle above and beyond: 14.5 Million Cycles (Verification ID: V875753)
• Patented Quick Reversible latchbolt — reverse handing without disassembling the lock case
• Multi-function capability: 12 functions configurable from one ML2054 lockbody
• Heavy-gauge steel lockcase 5-7/8" x 4" x 15/16"; 1" stainless steel deadbolt, 1" throw
• 3/4" (19mm) throw anti-friction two-piece latchbolt requires less force to close
• Wide variety of trim designs including Muséo®, Vineyard™, Behavioral Health (BHSS/BLSS)
• Status indicator options for locked/unlocked visibility (sectional and escutcheon trim)
• Motorized Electric Latch Retraction (MELR) available for ML20900 series
• Thru-bolted trim designs for proper alignment and increased security
• Can be used with new or existing Corbin Russwin key systems; accepts most other manufacturers' cylinders
• UL/cUL listed, UL10C positive pressure; 3-hour fire door up to 4' x 10' single or 8' x 10' pair
• Ten-year mechanical warranty; five-year MELR; two-year electrical

Technical Specifications

• Grade: ANSI/BHMA A156.13 Series 1000, Operational and Security Grade 1
• Handing: Handed; quick reversible — re-handed without disassembling the lock case
• Door Thickness: 1-3/4" (44mm) standard; optional thicknesses available
• Backset: 2-3/4" (70mm)
• Lockcase: Heavy-gauge steel, 5-7/8" (149mm) x 4" (102mm) x 15/16" (24mm)
• Armored Front: Wrought brass, bronze, or stainless steel, 8" x 1-1/4"
• Latchbolt: 2-piece mechanical with anti-friction insert, 5/8" x 1" x 3/4" (19mm) throw
• Auxiliary Latchbolt: 9/16" (14mm) effective throw; deadlocking
• Deadbolt: One-piece stainless steel, 19/32" x 1-1/4" x 1" (25mm) throw
• Strike: Wrought brass, bronze, or stainless steel, ANSI straight lip, 4-7/8" x 1-1/4" x 1-1/8" lip to center
• Cylinder: Brass, 6-pin L4 keyway, 0-bitted standard
• Spacing: C. to c. knob/lever to cylinder: 3-5/8" (92mm); knob/lever to thumbturn: 2-7/16" (62mm)
• Certifications: ANSI/BHMA A156.13 Grade 1; UL/cUL UL10C 3-hour positive pressure; ADA A117.1; California State Fire Marshal; Windstorm/Hurricane certified
• Warranty: Ten-year mechanical; five-year MELR; two-year electrical

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Corbin Russwin Quality?

Corbin Russwin ML2000 Series mortise trim products deliver professional-grade reliability with heavy-gauge steel construction and brass or bronze substrate, backed by UL cycle testing completed at an exceptional 14.5 Million Cycles (Verification ID: V875753). The ML2050 is covered by a 10 Year Limited warranty, providing long-term confidence for facility managers and installers alike. Engineered for demanding commercial applications where dependable performance, design flexibility, and consistent aesthetics are essential.
