Eaton Crouse-Hinds 2" Form 7 Wedge Nut Cover with Integral Gasket, Sheet Steel

Eaton Crouse-Hinds 2" Form 7 Wedge Nut Cover with Integral Gasket

Professional-Grade Condulet Cover for Secure Electrical Connections

The Eaton Crouse-Hinds 2" Form 7 Wedge Nut Cover with Integral Gasket is a premium condulet cover engineered for reliable electrical system protection in ordinary locations. This sheet steel cover delivers superior sealing performance and secure access for 2" trade size condulet installations in commercial and industrial electrical systems.

Key Features & Benefits

Superior Sealing Protection

• Integral Gasket Design - Built-in gasket ensures consistent weatherproof seal without separate components
• Form 7 Configuration - Optimized cover design provides maximum protection for condulet body connections
• Precision Manufacturing - Engineered tolerances ensure proper fit and reliable sealing performance
• Weather Resistance - Protects internal connections from moisture, dust, and environmental contaminants

Professional Installation Features

• Wedge Nut System - Secure fastening mechanism provides reliable cover retention and easy maintenance access
• Sheet Steel Construction - Durable material offers excellent strength-to-weight ratio for long-term performance
• Compact Profile - Low-profile design minimizes space requirements in tight installations
• NEC/CEC Compliant - Meets electrical code requirements for ordinary location installations

Maintenance & Service Advantages

• Quick Access Design - Wedge nut system allows rapid cover removal for wire pulling and connections
• Corrosion Resistance - Sheet steel construction with protective finish ensures long service life
• Gasket Integrity - Integral gasket design eliminates gasket loss during maintenance procedures

Technical Specifications

This Form 7 wedge nut cover is designed for 2" trade size condulet bodies in sheet steel construction. The cover measures 7 inches in height, 3 inches in length/depth, and 0.84 inches in width, with a total weight of 0.46 pounds. The integral gasket design ensures reliable sealing performance while the wedge nut fastening system provides secure retention. Engineered for NEC/CEC compliance in ordinary/non-hazardous locations, this cover delivers professional-grade protection for electrical connections.

Installation Process

1. Verify condulet body is properly installed and conduit connections are complete
2. Inspect integral gasket for proper seating and any damage before installation
3. Position cover over condulet body opening, ensuring proper alignment with mounting points
4. Insert wedge nut fasteners and tighten to manufacturer specifications for secure retention
5. Verify gasket compression is uniform around the entire perimeter for weatherproof seal
6. Test cover security and gasket seal integrity before energizing circuit

Applications

Perfect for:

• Commercial Buildings - Office complexes, retail centers, and institutional facilities
• Industrial Facilities - Manufacturing plants, processing facilities, and distribution centers
• Municipal Infrastructure - Schools, government buildings, and public facilities
• Electrical Distribution Systems - Panel connections, motor control centers, and switchgear installations
• Conduit System Extensions - Junction points and direction changes in raceway systems
• Equipment Connections - Machinery hookups and electrical equipment terminations
• Maintenance Access Points - Locations requiring periodic wire pulling or connection inspection
• Code-Compliant Installations - Projects requiring NEC/CEC adherence in ordinary locations

Condulet Cover System Benefits

Form 7 wedge nut covers provide superior protection compared to standard threaded covers by offering more secure retention and better sealing performance. The wedge nut system distributes clamping force evenly around the gasket perimeter, creating a more reliable weatherproof seal. This design also allows for faster maintenance access since wedge nuts can be operated more quickly than threaded connections, reducing labor time during service calls.

Why Choose Integral Gasket Design?

The integral gasket construction eliminates the risk of gasket loss during maintenance procedures while ensuring consistent sealing performance throughout the cover's service life. This design reduces installation time by eliminating separate gasket handling and positioning, while the sheet steel construction provides excellent durability and corrosion resistance. Trusted by electrical professionals for over 100 years, Eaton Crouse-Hinds condulet covers deliver the reliability and performance demanded in professional electrical installations.
