Eaton Crouse-Hinds 3" FMC 90° Squeeze Connector, Non-Insulated, Zinc Die Cast

(No reviews yet) Write a Review

Model: 745DC
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$199.94
$130.42
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks

Eaton Crouse-Hinds 3" FMC 90° Squeeze Connector, Non-Insulated, Zinc Die Cast

Professional-Grade Right Angle Flexible Metal Conduit Connection

The Eaton Crouse-Hinds 3" FMC 90° Squeeze Connector is a premium right-angle fitting engineered for professional flexible metal conduit installations. This zinc die cast squeeze-type connector delivers superior dimensional stability and corrosion resistance for commercial and industrial electrical systems requiring space-efficient 90-degree conduit transitions.

Key Features & Benefits

Superior Construction & Durability

  • Zinc Die Cast Construction - Precision casting ensures dimensional accuracy and superior corrosion resistance compared to standard steel fittings
  • 90° Angle Design - Space-saving right-angle configuration eliminates need for multiple fittings in tight installations
  • Squeeze-Type Connection - Tool-free installation with secure mechanical grip on flexible metal conduit
  • Non-Insulated Throat - Maintains grounding continuity through the fitting for enhanced electrical safety

Professional Installation Advantages

  • 3" Trade Size - Accommodates large wire bundles and high-capacity electrical feeds
  • Precision Threading - Smooth engagement with conduit systems and enclosures
  • Compact Profile - Reduces installation space requirements in crowded electrical panels
  • NEC/CEC Compliant - Meets code requirements for flexible metal conduit systems

Technical Specifications

This 3" trade size squeeze connector features zinc die cast construction with non-insulated throat design for optimal grounding continuity. The 90-degree angle configuration measures 11" width x 8.2" height x 7.8" depth, weighing 4.05 pounds for substantial durability. Compatible with standard flexible metal conduit systems and designed for ordinary/non-hazardous locations per NEC/CEC standards.

Installation Process

  1. Verify conduit end is cut square and deburred to prevent damage to conductors
  2. Insert flexible metal conduit fully into the squeeze connector body
  3. Tighten squeeze mechanism to secure conduit with proper mechanical grip
  4. Thread connector into electrical enclosure or junction box
  5. Verify grounding continuity through non-insulated throat design
  6. Complete conductor installation following NEC/CEC requirements

Applications

Perfect for:

  • Motor Control Centers - Right-angle connections to drive panels and variable frequency drives
  • Industrial Equipment - Flexible connections to machinery requiring vibration isolation
  • Commercial Electrical Panels - Space-efficient conduit routing in crowded switchgear
  • HVAC Systems - Connections to large commercial air handling units and controls
  • Process Equipment - Chemical and manufacturing facility electrical connections
  • Data Centers - Power distribution to server racks and UPS systems
  • Hospital Facilities - Medical equipment power feeds requiring flexible connections
  • Educational Institutions - Laboratory and workshop electrical installations

Flexible Metal Conduit System Benefits

Flexible metal conduit systems with squeeze connectors provide superior vibration resistance and thermal expansion accommodation compared to rigid conduit installations. The flexible design absorbs mechanical stress while maintaining electrical continuity, making it ideal for equipment connections subject to movement or thermal cycling.

Why Choose Zinc Die Cast Construction?

Zinc die cast construction delivers precision dimensional control and exceptional corrosion resistance for long-term reliability. The casting process creates smooth internal surfaces that protect conductor insulation during installation, while the zinc material provides natural corrosion protection superior to standard steel fittings. This professional-grade construction ensures decades of reliable service in demanding commercial and industrial environments.

Manufacturer Resources

Product Specs

Area Classification:
Ordinary/Non-Hazardous Locations
Conduit Type:
FMC
Connector Type:
90 Degree angle
Insulator:
Non-insulated
Material:
Zinc die cast
Product Height:
8.2 in
Product Length Depth:
7.8 in
Product Weight:
4.05 lb
Product Width:
11 in
Standards Type:
NEC/CEC
Trade Size:
3"
Product Type:
Squeeze Type Connector
Product Group:
Electrical Fitting
Department:
Electrical
Product Subgroup:
Squeeze Type Connector
