CU TP 1HL LUG LONGBRL 250 1/2B YEL
Manufacturer Resources
Product Specs
- Cable Size:
- 250 kcmil
- Country Of Origin:
- Mexico (MX)
- Product Group:
- Wire Termination
- Product Type:
- Long Barrel
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Stud Size:
- 1/2 in
- Sub Brand Label:
- Blackburn
- Type2:
- Cable or wire lug
- Department:
- Electrical
- Product Subgroup:
- Lugs
- Product Color:
- Yellow
- Product Material:
- Copper
Blackburn CTL250L-12 – Frequently Asked Questions
1) What wire size does the Blackburn CTL250L-12 compression lug take?
The CTL250L-12 is sized for 250 kcmil copper conductor. It is a one-hole, long barrel compression lug, so it crimps onto the cable rather than clamping with a setscrew. Copper only, not dual-rated for aluminum.
2) What does the yellow color code on this Blackburn compression lug mean?
Yellow is the die color code for this lug. The CTL250L-12 is marked yellow so the crimper operator matches the correct die set and number of crimps to the barrel. Use the die color stamped on the barrel, not the conductor size alone, when setting up the tool.
3) Why choose a long barrel lug instead of a standard barrel for a 250 kcmil feeder?
A long barrel takes more crimps over a greater contact length, which is what you want on high-current feeders, service entrance terminations and anywhere vibration or thermal cycling is a factor. A standard short barrel is fine for lighter branch work. The CTL250L-12 is the long barrel version for 250 kcmil copper.
4) Do I need a special tool to install this lug, or can I bolt it on?
This is a compression lug, not a mechanical setscrew lug. The barrel has to be crimped onto the 250 kcmil conductor with a hydraulic or battery crimper and the matching die before the tongue gets bolted down on the 1/2 inch stud. If you do not have a crimper on site, specify a mechanical lug instead.
5) Is the Blackburn CTL250L-12 sold individually or in a bag of ten?
It is sold each, so order one per termination. On a three-phase feeder with a neutral and a ground, that is five pieces per end.
