CU TP 1HL LUG LONGBRL 600 5/8B GRN
Manufacturer Resources
Product Specs
- Cable Size:
- 600 kcmil
- Country Of Origin:
- Mexico (MX)
- Product Group:
- Wire Termination
- Product Type:
- Long Barrel
- Selling Unit Of Measure:
- each
- Standards:
- UL E9809
- Stud Size:
- 5/8 in
- Sub Brand Label:
- Blackburn
- Type2:
- Cable or wire lug
- Department:
- Electrical
- Product Subgroup:
- Lugs
- Product Color:
- Green
- Product Material:
- Copper
Blackburn CTL600L-58 – Frequently Asked Questions
1) What wire size does the Blackburn CTL600L-58 lug take?
The CTL600L-58 is sized for 600 kcmil copper conductor. It's a one-hole, long barrel compression lug, so the conductor gets crimped into the barrel rather than clamped by a setscrew. If your feeder is a different kcmil size, you need a different part number in the series, since compression lugs are single-size only.
2) Is this a copper lug or aluminum?
Solid copper, tin plated, which is what the CU TP in the description means. Tin plating is why it's suitable for copper conductor terminations in both dry and damp locations and resists the oxide film bare copper builds up on a bolted joint.
3) Why is this lug green, and does the color mean anything for installation?
Green on the CTL600L-58 is the grounding color code, and it's a ground lug by design. The color tells the next electrician or inspector at a glance that the conductor landing there is an equipment grounding or bonding conductor, which matters on a panel or switchgear inspection.
4) What is a long barrel lug for, versus a standard barrel?
A long barrel takes two crimps instead of one, which gives more contact area and pull-out strength on a heavy conductor. At 600 kcmil that matters, which is why the CTL600L-58 is built this way. It also means you need a die and tool rated for the long barrel and that conductor size; a short-barrel die set won't give you a compliant crimp.
5) Does the CTL600L-58 come with mounting hardware?
No. The lug is sold individually, each, and it's the terminal only. The 5/8 inch bolt, nut, and any Belleville or flat washers for the bus connection are separate, as is the crimp die for the barrel.
