Detex Classroom Security Lever Trim with S Lever and Wide Escutcheon for 10 Series Rim Exit Devices

Detex Classroom Security Lever Trim with S Lever and Wide Escutcheon for 10 Series Rim Exit Devices

(No reviews yet) Write a Review

Model: 10-DS-626-RHR

In Stock (leaves warehouse same day if ordered before 3pm ET)

$585.04
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Detex Classroom Security Lever Trim with S Lever and Wide Escutcheon for 10 Series Rim Exit Devices

Professional Classroom Security Solution with Key-Operated Lever Control

The Detex Classroom Security Lever Trim provides secure access control for educational and institutional facilities using 10 Series Double Cylinder Wide Strike Rim Exit Devices. This professional-grade trim features a robust "S" lever handle on a 9-1/16" x 2-3/4" wide escutcheon plate, allowing users to lock or unlock the lever from either side using a key. The Right Hand Reverse (RHR) configuration is field reversible for installation flexibility, and the 626/US26D Satin Chrome finish delivers a clean, modern aesthetic suitable for contemporary architectural environments.

Professional Features & Benefits

  • Escutcheon Dimensions: 9-1/16" H x 2-3/4" W wide escutcheon plate provides added strength and standardized fit for commercial applications.
  • Classroom Security Function: Key from either side locks or unlocks the lever for secure control, ideal for quick lockdown and access management in educational facilities.
  • Field Reversible Configuration: Right Hand Reverse (RHR) handing can be adapted during installation or retrofits for maximum flexibility.
  • Heavy-Duty Construction: Commercial-grade materials and robust "S" lever design engineered for high-traffic institutional environments.
  • 10 Series Compatibility: Specifically designed for use with Detex 10 Series Double Cylinder Wide Strike Rim Exit Devices for seamless integration.
  • Flexible Cylinder Options: Supplied less mortise cylinder, allowing end users to pair with their preferred key system for customized security.
  • Professional Finish: 626/US26D Satin Chrome finish provides durability and visual appeal for modern facilities.
  • Design Consistency: Part of Detex modular hardware system with alternate lever styles (J, Q, T, U, FSB1076) available for facility-wide coordination.

Technical Specifications

  • Compatible Series: 10 Series Rim Exit Devices
  • Product Category: Parts and Accessories
  • Product Group: Exit Devices and Trim
  • Product Subgroup: Exit Devices - Vertical Rod
  • Product Type: Exit Devices - Vertical Rod
  • Subcategory: Panic Device Trims – Rim Device Trim

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Classrooms and Lecture Halls
  • Educational Institution Security Systems
  • Government and Municipal Buildings
  • Public Training Centers
  • School Campus Access Control
  • Institutional Facility Renovations
  • High-Traffic Commercial Buildings

Why Choose Detex Quality?

Detex Classroom Security Lever Trim delivers professional-grade reliability with commercial-grade construction and field-reversible configuration for demanding institutional applications. The robust "S" lever design and wide escutcheon plate construction provide exceptional durability for high-use educational environments. Engineered as part of the modular Detex hardware system where dependable security performance is essential.

Manufacturer Resources

Product Specs

Subcategory:
Panic Device Trims – Rim Device Trim
Product Type:
Exit Devices - Vertical Rod
Product Group:
Exit Devices and Trim
Compatible Series:
10 Series Rim Exit Devices
Product Subgroup:
Exit Devices - Vertical Rod
Product Category:
Parts and Accessories
Department:
Door Hardware

Detex 10-DS-626-RHR – Frequently Asked Questions

1) How does the classroom security function actually work on this Detex lever trim?
A key from either side locks or unlocks the lever. Locked, the outside lever is dead and entry requires the key; unlocked, the lever retracts the rim device latch for free passage. Egress from inside is always through the push bar on the exit device, so a lockdown never traps anyone. That key-both-sides control is what makes it practical for classroom and lecture hall openings.
2) Do I need to order a cylinder with the Detex 10-DS classroom trim?
Yes. The trim ships less mortise cylinder, so you supply your own to match the building's key system. Order a mortise cylinder in your existing keyway and have the locksmith key it into the master system before install.
3) I need left hand reverse. Is this trim handed?
It's listed in Right Hand Reverse but the handing is field reversible, so it can be set the other way during installation or a retrofit. No separate part number needed for the opposite hand.
4) Is the Detex 10-DS-626-RHR classroom lever trim a complete exit device, or do I still need the panic hardware?
It is trim only - an S lever on a 9-1/16 inch by 2-3/4 inch wide escutcheon that mounts to a Detex 10 Series rim exit device for outside key-controlled entry. The panic device itself is a separate purchase. If you need a complete device rather than trim, a unit such as the Von Duprin 8827-3FT wide stile surface vertical rod exit device or the Imperial USA ED-VR531 500 Series wide stile vertical rod device is a full exit device assembly.
5) What do I use on a door where no outside key entry is needed at all?
Skip the lever trim and use an exit-only device, which has no outside operating trim. The Marks USA M9900VR 36 inch by 84 inch vertical rod panic device is listed as exit only and non-handed, and the Cal-Royal 9860 surface vertical rod device is also exit only. The Detex 10-DS trim exists specifically to give key-controlled lever entry from the outside for classroom lockdown control, so it is unnecessary on an egress-only opening.
6) My opening is fire rated - can I use this Detex trim setup there?
The Detex 10-DS trim is built for Detex 10 Series rim exit devices and carries no fire rating statement of its own, so the rating is driven by the device and opening assembly. For an opening where you need a labeled device, the Delaney F9100 Series is a Grade 1 fire rated heavy duty vertical rod device, and the Marks USA M9900FVR 36 inch by 84 inch and MARM9900F-VR 48 inch by 84 inch are fire rated vertical rod exit devices.
7) Will this Detex classroom trim fit a surface vertical rod device like the Von Duprin 8827?
No. The Detex 10-DS trim is made for Detex 10 Series rim exit devices, which use a rim latch and a different trim prep. The Von Duprin 8827-3FT is an 88 Series surface vertical rod device and takes its own trim. Match trim to the device family it was designed for rather than by finish or lever shape.
8) Will a 9-1/16 inch escutcheon fit my door stile?
The escutcheon plate measures 9-1/16 by 2-3/4 inches, so the stile has to be at least 2-3/4 inches wide plus room for the fixing holes. That rules out most narrow aluminum stile storefront doors. On hollow metal and wide stile doors it mounts without issue, and the wide plate also spreads the load on high-traffic openings.
9) Can I use this trim to convert an exit-only vertical rod device to keyed entry?
No. Exit-only devices like the Cal-Royal 9860, the Imperial USA ED-VR531 or the Marks USA M9900VR have no outside trim prep at all, and this Detex lever trim will not add one. To get keyed outside entry you need a device built to accept trim, and in this case specifically a Detex 10 Series double cylinder wide strike rim device.
10) Does the Detex 10-DS trim come with a cylinder, and does that differ from the exit devices?
The Detex 10-DS classroom lever trim ships less mortise cylinder, so you supply the cylinder to match your existing key system. Exit-only devices such as the Cal-Royal 9860 and the Marks USA M9900VR are keyless by function and take no cylinder at all, since they provide egress only.
11) What finish does the Detex 10-DS trim come in, and can I match other levers on campus?
It is finished in 626/US26D satin chrome, the standard commercial satin chrome that pairs with most institutional lever hardware. Detex also offers alternate lever styles (J, Q, T, U and FSB1076) on the same trim system if you are standardizing a different lever shape across a building.
12) What prep work does the Detex classroom lever trim need on the door?
Use the Detex template to lay out the mounting holes; the trim fixings pass through the door and tie into the rim device chassis on the push side, and the cylinder needs its own through-hole. Confirm door thickness, stile width and handing against the template before drilling, then set the lever so it swings freely through its full range and retracts the rim latch cleanly.
