DiodeLED DI-CPCHB-RECEPTACLE-96 Recessed Channel for LED Tape Light, Chromapath®

DiodeLED DI-CPCHB-RECEPTACLE-96 Recessed Channel for LED Tape Light, Chromapath®

(No reviews yet) Write a Review

Model: DI-CPCHB-REC-96

In Stock (leaves warehouse same day if ordered before 3pm ET)

$171.99
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
"

DiodeLED DI-CPCHB-RECEPTACLE-96 Recessed Channel for LED Tape Light, Chromapath®

The DiodeLED DI-CPCHB-RECEPTACLE-96 is a recessed aluminum channel engineered to house and protect LED tape light while delivering the clean, seamless look that defines the Chromapath® product line. Measuring 96-Inch in length by 0.74-Inch in width and 0.49-Inch in height, this channel is sized for extended linear lighting runs where discreet, flush-mounted illumination is required. Whether integrated into cabinetry, coves, ceilings, or millwork, this recessed profile allows LED tape light to be mounted below the surface plane, minimizing glare and maximizing diffusion for a professional finished appearance.

Key Features

  • Extended Length: 96-Inch channel length supports long, continuous LED tape light runs without unnecessary splicing or additional hardware.
  • Compact Profile: 0.74-Inch width and 0.49-Inch height keep the channel low-profile and unobtrusive once installed.
  • Recessed Design: Purpose-built recessed configuration allows the channel to sit flush or below the mounting surface, concealing the LED tape and reducing visible hot spots.
  • Chromapath® Compatibility: Part of the Chromapath® channel system, designed to pair with corresponding LED tape light and diffusion accessories for a coordinated linear lighting solution.
  • Versatile Mounting: Suited for cabinetry, shelving, coves, soffits, and other architectural applications where a hidden light source is desired.
  • Simplified Tape Light Management: The channel body organizes and protects the LED tape light, helping maintain a straight run and shielding the strip from incidental contact or damage.

Technical Specifications

  • Length: 96-Inch
  • Width: 0.74-Inch
  • Height: 0.49-Inch
  • Series: Chromapath®
  • Configuration: Recessed Channel

Typical Applications

  • Under-Cabinet and Cabinet Interior Lighting
  • Cove and Soffit Lighting Installations
  • Architectural Millwork and Shelving Accents
  • Residential and Commercial Linear LED Lighting Systems
  • Extended-Run LED Tape Light Projects

Why DiodeLED?

DiodeLED's Chromapath® recessed channel system is built to give LED tape light installations a clean, integrated appearance while protecting the tape from damage and simplifying alignment over long runs. The 96-Inch DI-CPCHB-RECEPTACLE-96 channel gives installers a purpose-fit housing option for extended linear lighting layouts, supporting consistent, professional results in cabinetry, coves, and architectural lighting applications.

"

Manufacturer Resources

Product Specs

list_batch:
DIO-20260924
Product Type:
LED Tape Light & Channel
Series:
Chromapath
Configuration:
Recessed
Department:
Electrical
Product Subgroup:
Light Fixtures
Product Group:
Lighting

DiodeLED DI-CPCHB-REC-96 – Frequently Asked Questions

1) What are the dimensions of the DiodeLED Chromapath DI-CPCHB-REC-96 recessed channel, and will LED tape fit inside it?
The DI-CPCHB-REC-96 channel runs 96 inches long with a 0.74 inch width and 0.49 inch height. That interior space is what houses the LED tape light, so measure your tape width against the 0.74 inch channel width before cutting anything. The profile is intended for Chromapath tape light and diffusion accessories.
2) Is the DI-CPCHB-REC-96 a surface mount or recessed channel?
Recessed. The DI-CPCHB-REC-96 is built to drop into a routed or milled pocket so it sits flush with or below the mounting surface. If you need a channel that mounts on top of a finished surface with no routing, this is the wrong profile and you want a surface mount Chromapath channel instead.
3) Does the DI-CPCHB-REC-96 channel come with a diffuser lens and end caps?
The DI-CPCHB-REC-96 is the channel body itself. Diffusion is handled by the separate Chromapath diffusion accessories designed to pair with it, so specify your lens, and the tape light, as separate line items when you build the order.
4) Why use a recessed aluminum channel instead of sticking LED tape straight to the millwork?
Two reasons that matter on finished work. Recessing the tape below the surface plane minimizes glare and spreads the light, so you do not see the individual diodes as hot spots. The channel body also keeps the tape straight over a long run and shields it from incidental contact or damage, which is the usual failure point on bare adhesive-mounted tape in cabinetry and shelving.
5) What is the exact part number I should order for the 96 inch DiodeLED recessed Chromapath channel?
Order DI-CPCHB-REC-96. DiodeLED also publishes it as DI-CPCHB-RECEPTACLE-96, which is the same 96 inch recessed Chromapath channel.
6) Is this channel suitable for cove and soffit lighting, or only under-cabinet?
Both. The recessed Chromapath profile is used in cabinet interiors and under-cabinet work, coves and soffits, architectural millwork and shelving accents, and general linear LED runs in residential and commercial spaces. Anywhere you want the light visible but the source hidden, the 0.49 inch height keeps the pocket shallow.
