Thomas & Betts LD2-D Luminaire Disconnect 600V Orange Polycarbonate with Finger-Safe Design

Thomas & Betts LD2-D Luminaire Disconnect 600V Orange Polycarbonate with Finger-Safe Design

Professional luminaire disconnection with enhanced safety features

The Thomas & Betts LD2-D Luminaire Disconnect delivers reliable 600V electrical disconnection in a compact orange polycarbonate housing. Featuring oversized tin-plated brass contacts for improved conductivity and reduced temperature rise, this disconnect includes integral wire leads for simplified installation and a fool-proof design that ensures proper mating. The finger-safe line side design prevents installer contact with hot contacts, while the rounded compact profile fits through 1/2" knockouts for versatile mounting options.

Professional Features & Benefits

• 600V Voltage Rating: Handles high-voltage applications with reliable electrical isolation and safety compliance.
• Oversized Tin-Plated Brass Contacts: Deliver superior conductivity and minimize temperature rise for consistent long-term performance.
• Finger-Safe Line Side Design: Protects installers from accidental contact with energized components during installation and maintenance.
• Polycarbonate Construction: Provides durable housing with UL 94 V-2 flammability rating and 105�C temperature rating for demanding environments.
• Compact Profile Design: Fits through 1/2" knockouts enabling installation in space-constrained applications.
• CSA and UL Certifications: Meets rigorous safety standards for professional electrical installations.
• Fool-Proof Mating Design: Ensures proper connection orientation preventing installation errors and enhancing system reliability.

Technical Specifications

• Color: Orange
• Department: Electrical
• Disconnect Type: Luminaire
• Flammability Rating: UL 94 V-2
• Inner Package: 50
• Length Inches: 13.66
• Material: Polycarbonate
• Order Multiple: 50
• Outer Package: 250
• Package Height: 14
• Package Length: 21
• Package Type: Bulk
• Package Width: 11.5
• Product Group: Circuit Protection
• Product Subgroup: Disconnects
• Rohs Compliance: Yes
• T B Sold In Uom: Each
• T B Weight Per Uom: 4.13 lbs. per 100
• Temperature Rating: 105�C
• Terminal Series: LD
• Voltage Rating: 600V
• Wire Range: 18 Solid

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Luminaire and lighting fixture disconnection
• Commercial lighting systems
• Industrial facility lighting
• Electrical panel and switchgear applications
• Maintenance and service disconnects
• Circuit protection installations
• High-voltage electrical systems

Why Choose Thomas & Betts Quality?

Thomas & Betts delivers proven reliability through CSA and UL certifications, ensuring compliance with professional electrical standards. The polycarbonate construction with 105�C temperature rating and UL 94 V-2 flammability rating provides long-term durability in demanding electrical environments, while RoHS compliance demonstrates commitment to environmental responsibility.
