Don-Jo 1724 Magnetic Catch — 3-1/8" Length, 14 lb. Load Capacity, Brass

The Don-Jo 1724 Magnetic Catch is a commercial-grade door hardware accessory engineered for reliable, low-maintenance door retention. Constructed from solid brass and measuring 3-1/8" in length by 1-3/4" in width, this magnetic catch delivers a 14 lb. load capacity to keep doors securely held in position. Conforming to ANSI B43161, the 1724 is packaged with multiple strikes for flexible installation and is available in finishes 605 and 626 to complement a wide range of door hardware aesthetics.

Key Features

  • Precise Dimensions: Measures 3-1/8" in length and 1-3/4" in width, providing a compact yet effective footprint for a variety of door applications.
  • Reliable Load Capacity: Rated at 14 lbs. of holding force, ensuring consistent and dependable door retention in commercial environments.
  • Solid Brass Construction: Manufactured from brass for long-lasting durability, corrosion resistance, and a refined appearance suited to commercial and upscale residential settings.
  • Multiple Strikes Included: Packaged with multiple strikes to accommodate varied door and frame configurations right out of the box.
  • Dual Finish Availability: Available in finish codes 605 and 626 to coordinate with existing door hardware and architectural finishes.
  • ANSI Compliant: Meets ANSI B43161 standards, confirming adherence to recognized industry performance benchmarks for magnetic catches.
  • Convenient Shelf Pack: Sold in shelf packs of 10, making this an efficient choice for contractors, distributors, and facility managers stocking multiple units.

Certifications & Compliance

  • ANSI B43161 Compliant
  • Commercial Grade

Technical Specifications

  • Product Group: Door Trim and Accessories
  • Subcategory: Latches & Catches
  • Product Subgroup: Door Latches and Catches
  • Commercial/Residential: Commercial
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities

Why Don-Jo 1724?

Don-Jo magnetic catches are built to commercial-grade standards, with the 1724 model offering solid brass construction and a 14 lb. load capacity that meets ANSI B43161 requirements. Engineered for demanding commercial applications, the 1724 delivers consistent door retention performance with the added convenience of multiple included strikes and a choice of professional finishes — making it a dependable solution for facility managers and hardware professionals alike.

Manufacturer Resources

DON-JO Bolts & Latches

Product Specs

Product Group:
Door Trim and Accessories
Subcategory:
Latches & Catches
Product Subgroup:
Door Latches and Catches
Product Type:
Magnetic Catches
Commercial/Residential:
Commercial
ANSI/BHMA:
B43161
Product Model:
1724
Product Category:
Door Trim and Accessories
Product Substrate:
Brass
Department:
Door Hardware

Don-Jo 1724-626 – Frequently Asked Questions

1) How much weight will a Don-Jo 1724 magnetic catch hold?
The 1724 magnetic catch is rated at 14 lbs of holding force. That is enough to keep a light interior door, cabinet door, or closet leaf closed against normal traffic, but it is a catch and not a latch, so it holds a door in position rather than securing it. If you need a door held open or held closed against wind load or heavy use, a magnetic catch at this rating is not the right part.
2) What size is the Don-Jo 1724 magnetic catch, and will it fit a narrow door stop?
Body measures 3-1/8 inches by 1-3/4 inches. Lay that footprint against your stop or frame face before you cut in: on a standard commercial stop you have room, but on a thin residential stop the 1-3/4 inch dimension is the one that runs out first.
3) Do I have to buy a separate strike for the Don-Jo 1724 magnetic catch?
No. Multiple strikes ship in the box with the 1724, so you can match the strike to the door and frame configuration you actually have without a second order line.
4) Does the Don-Jo 1724 magnetic catch meet an ANSI/BHMA standard?
It carries ANSI/BHMA B43161. For a facility spec that calls out a BHMA designation for catches, that is the number to put on the submittal.
5) Can I use the Don-Jo 1724 magnetic catch on a fire rated door?
No. A magnetic catch is a door retention accessory, not a latch, and a fire door assembly has to positive-latch. Use the 1724 on non-rated openings, closets, cabinet and cupboard doors, and pair rated openings with a listed latching device instead.
6) What finishes does the Don-Jo 1724 magnetic catch come in?
Two: 605 polished brass and 626 satin chrome. If the rest of the openings in the building are on satin chrome lever trim, 626 is the match; 605 goes with polished brass lock trim and older bright-brass suites.
7) Is the Don-Jo 1724 magnetic catch solid brass or plated steel?
Brass is the substrate. That matters in damp or coastal work and in healthcare and hospitality interiors where a plated steel catch starts showing corrosion at the strike face after a few seasons.
8) How is a magnetic catch different from a roller catch or a ball catch?
A magnetic catch holds by magnet against a steel strike, so there is no mechanical detent to wear out and no click as the door closes. That makes it the quiet option for offices, exam rooms and libraries. A roller or ball catch gives you an adjustable resistance you can dial up, which is what you want when the door needs a firmer hold than the 14 lbs the 1724 provides.
9) Is the Don-Jo 1724 a commercial magnetic catch or a residential one?
Commercial grade. Don-Jo builds the 1724 for office, education, healthcare, retail, multi-tenant residential, government and warehouse openings, which is why it comes brass-bodied with a BHMA designation rather than as a builder-grade catch.
