Don-Jo 2080 Gravity Coordinator, 5-3/8" x 7" — Adjustable, Field Reversible, Brass

Don-Jo 2080 Gravity Coordinator, 5-3/8" x 7" — Adjustable, Field Reversible, Brass

(No reviews yet) Write a Review

Model: 2080-626
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$116.46
$102.29
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 2080 Gravity Coordinator — Adjustable, Field Reversible Brass Door Coordinator, 5-3/8" x 7"

The Don-Jo 2080 Gravity Coordinator is a commercial-grade door arm-type coordinator engineered to ensure proper sequencing of double-door openings. Measuring 5-3/8" x 7" and constructed from brass with a 626 satin chrome finish, this gravity coordinator delivers reliable, adjustable performance in demanding commercial environments. Its field-reversible design and adjustable construction make it a versatile solution for a wide range of door configurations and installation requirements.

Key Features

  • Precise Dimensions: Measures 5-3/8" x 7" to accommodate standard commercial double-door applications with consistent, reliable sequencing.
  • Door Arm Type Design: Engineered as a door arm-type gravity coordinator, ensuring proper door closing sequence to maintain security and fire-rated door integrity.
  • Adjustable Construction: Fully adjustable mechanism allows fine-tuning to match specific door widths, weights, and closing speeds for optimal performance.
  • Field Reversible: Can be reversed in the field without special tools, providing installation flexibility for left-hand or right-hand door configurations.
  • Brass Construction: Manufactured from brass for durability and long-term reliability in high-traffic commercial settings.
  • 626 Finish: Features a 626 satin chrome finish that complements a wide range of commercial door hardware and architectural styles.
  • Commercial Grade: Designed and rated for commercial applications where dependable door coordination is essential.

Technical Specifications

  • Product Group: Door Controls
  • Subcategory: Door Coordinators
  • Product Subgroup: Door Coordinators
  • Product Type: Door Coordinators
  • Commercial/Residential: Commercial
  • Product Size: 5 3/8" x 7"
  • Product Category: Door Controls
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings with Double-Door Entrances
  • Educational Facilities and School Corridors
  • Healthcare Institutions and Hospital Doorways
  • Retail Establishments with High-Traffic Entry Points
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential and Mixed-Use Properties

Why Don-Jo 2080?

Don-Jo 2080 Gravity Coordinator products deliver professional-grade reliability through brass construction and a field-reversible, adjustable design built for the demands of commercial door hardware applications. The 2080's door arm-type mechanism ensures consistent door sequencing performance, making it a dependable choice for installers and facility managers who require precision and versatility in double-door coordination.

Manufacturer Resources

DON-JO Door Controls

Product Specs

Product Group:
Door Controls
Subcategory:
Door Coordinators
Product Subgroup:
Door Coordinators
Product Type:
Door Coordinators
Commercial/Residential:
Commercial
Product Model:
2080
Product Size:
5 3/8" x 7"
Product Category:
Door Controls
Product Substrate:
Brass
Department:
Door Hardware

Don-Jo 2080-626 – Frequently Asked Questions

1) What does a door coordinator like the Don-Jo 2080 actually do, and do I need one on my double doors?
A coordinator controls which leaf of a pair closes first. On a pair where the inactive leaf carries an astragal or an overlapping edge, the active leaf has to close last or it jams against the inactive one and neither latches. The Don-Jo 2080 is a gravity, door arm type coordinator: it holds the active leaf open until the inactive leaf has closed, then releases it to close and latch. If your pair has a center mullion, or the two leaves meet flush with no overlap and no astragal, you don't need a coordinator at all.
2) Is the Don-Jo 2080 a gravity coordinator or a bar type, and which should I use?
The 2080 is the gravity type. Gravity coordinators mount at one point on the frame soffit and use a pivoting arm, so they suit a straightforward pair where you want a small footprint and a field-adjustable hold. Bar type coordinators run the full width of the frame head and are generally what a spec calls out when both leaves need to be caught across the whole opening, or where brackets for closers and holders mount off the bar. ZenSupply carries bar types too: the ABH 3700 Series full bar coordinator with filler bar, and the Ives COR Series aluminum bar coordinators. If you want another gravity unit to compare against, the Ives COR7G/COR9G is brass and field adjustable like the 2080.
3) Do I have to order the Don-Jo 2080 handed, or does one part cover both left and right pairs?
One part covers both. The 2080 is field reversible, so the installer sets it for the hand of the opening on site without special tools and without a separate left or right SKU. That matters if you are stocking a truck or standardizing a building: one line item covers every pair regardless of which leaf is active.
4) How much room do I need at the frame head for the Don-Jo 2080 coordinator?
The 2080 measures 5-3/8 x 7 inches. Lay that out on the frame soffit before you commit, because closer shoes, electric strike wiring, and hold-open arms all compete for the same stretch of head. If the soffit is crowded across the full width of the opening, a stop mounted coordinator such as the Trimco 3094 mounts differently and may clear where a soffit mounted unit won't.
5) I'm coordinating a fire rated pair of doors. What should I be looking at?
For a fire rated pair, buy the coordinator that the fire listing calls for. ZenSupply carries coordinators we hold fire rating data on: the Ives COR Series aluminum bar coordinators and the Ives COR7G/COR9G brass gravity coordinator are both recorded as fire rated, the ABH 3700 Series full bar with filler bar is UL listed for fire door use, and Trimco's 3092 retracting arm and 3094 stop mounted coordinators are UL units. Match the coordinator to what the door and frame label and your opening schedule require.
6) What is an equivalent brass gravity coordinator to the Don-Jo 2080?
The Ives COR7G/COR9G is the closest peer to the Don-Jo 2080. Both are brass gravity coordinators with field-adjustable operation: the 2080 is a brass, field-reversible adjustable gravity coordinator at 5-3/8 in. x 7 in., and the COR7G/COR9G is a brass gravity coordinator with field-adjustable operation carrying a fire rating. If your opening is on a fire-rated pair, the Ives COR7G/COR9G is the direct brass-gravity alternate to specify.
7) What coordinator should I use instead of a gravity type on a fire-rated pair of doors?
Move to a bar-type coordinator. The Ives COR Series aluminum bar door coordinators (COR32, COR42, COR52, COR60, COR72) are UL listed and carry a fire rating, and the ABH 3700 Series is a full bar coordinator with filler bar that is UL listed and fire door compatible. Both mount across the frame head rather than working off the leaf like the Don-Jo 2080 gravity coordinator, and the bar length is matched to the opening width.
8) Can I adjust the Don-Jo 2080 for heavier doors or a slow closer?
Yes, the mechanism is adjustable, so you tune it on site to the door width, leaf weight, and closing speed you actually have rather than accepting one fixed release point. On a pair where the inactive leaf carries a vertical rod device and closes slowly, that adjustment is what stops the active leaf from arriving early and hanging up on the astragal.
9) Is the Don-Jo 2080 a direct swap for an existing gravity coordinator on my frame?
Treat it as a new install, not a drop-in. Coordinator mounting hole patterns are not standardized between makers, so pull the old unit, measure the existing holes against the 2080's 5-3/8 x 7 inch body, and expect to drill and tap fresh holes in the frame soffit. If the existing unit is an Ives brass gravity coordinator and you want to avoid re-prepping, the Ives COR7G/COR9G is the same brass gravity, field adjustable style from that brand.
10) My pair of doors keeps failing to latch on the active leaf. Will a coordinator fix that?
If the active leaf is closing before the inactive leaf and catching on the astragal or the overlapping edge, then yes, that is exactly what a gravity coordinator like the Don-Jo 2080 is for: it holds the active leaf back until the inactive one is shut. If both leaves are closing in the right order and the active leaf still won't latch, the problem is elsewhere, usually strike alignment, closer force, or a warped leaf, and a coordinator won't touch it.
11) What is the difference between a bar coordinator and the Don-Jo 2080 gravity coordinator?
The Don-Jo 2080 is a gravity, door arm type coordinator measuring 5-3/8 in. x 7 in. and sized to the hardware location rather than the opening width. A bar coordinator such as the ABH 3700 Series full bar coordinator with filler bar spans the full width of the frame head, so the bar has to be sized and filled to the opening. The Ives COR Series is the aluminum bar version of that same approach. Gravity units are the smaller footprint; bar units cover the full head.
12) Is a stop mounted coordinator the same thing as the Don-Jo 2080?
No. The Trimco 3094 is a UL stop mounted coordinator, which fastens to the frame stop, while the Don-Jo 2080 is a door arm type gravity coordinator, field reversible and adjustable in brass. They do the same sequencing job but land in different places on the frame, so the prep and the mounting surface are not interchangeable. Confirm which mounting your frame is prepped for before ordering either.
13) What coordinator works when the arm needs to retract out of the way of the door leaf?
The Trimco 3092 is a UL retracting arm coordinator, designed so the arm retracts during the sequence. The Don-Jo 2080 uses a fixed door arm type gravity mechanism that is adjustable and field reversible. If your opening has an overlapping astragal or a leaf path that the arm cannot stay parked in, the Trimco 3092 retracting arm design is the one to look at.
14) If I am standardizing coordinators across a building, which one covers the widest range of opening widths?
The Ives COR Series covers a range of aluminum bar coordinators - COR32, COR42, COR52, COR60 and COR72 - so a single series can be sized across different opening widths, and the ABH 3700 Series uses a filler bar to make up the span. The Don-Jo 2080 gravity coordinator is a fixed 5-3/8 in. x 7 in. unit that is adjustable and field reversible, so the same part number handles both handings without a width selection. Property managers repeating one part across many pairs often prefer the gravity unit for that reason; a bar series matches the opening width instead.
15) What finish does the Don-Jo 2080 gravity coordinator come in?
626 satin chrome is the only finish offered, and the body is brass underneath. On a coordinator that is usually a non-issue since the unit sits up on the frame soffit out of sight, but 626 is the standard commercial match if the rest of your closers, strikes, and lever trim are already satin chrome.
16) Is the Don-Jo 2080 coordinator meant for commercial openings or will it work on a residential pair?
It is a commercial product, brass bodied and built for the double door openings you find in offices, schools, healthcare corridors, retail entries, and multi-tenant buildings. Nothing stops it working on a residential pair of doors, but a residential pair only needs a coordinator if it has an astragal or overlapping leaves forcing a closing order.
