Don-Jo 534 MWA Metal-Wood Stud Combo Anchor 10" x 1-1/2" 18 Gauge Steel

Don-Jo 534 MWA Metal-Wood Stud Combo Anchor 10" x 1-1/2" 18 Gauge Steel

(No reviews yet) Write a Review

Model: 534-MWA

In Stock (leaves warehouse same day if ordered before 3pm ET)

$14.94
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 534 MWA Metal-Wood Stud Combo Anchor 10" x 1-1/2" 18 Gauge Steel

The Don-Jo 534 MWA is a commercial-grade Metal-Wood Stud Combo Anchor engineered for reliable door frame anchoring in both metal and wood stud wall applications. Constructed from 18-gauge steel (.050) and measuring 10" in length by 1-1/2" in width, this anchor provides a sturdy, versatile solution for securing door frames in a wide range of commercial construction environments. Sold in a shelf pack of 50, the 534 MWA is well-suited for contractors and installers requiring consistent, high-quality anchoring components across multiple installations.

Key Features

  • Dual-Compatibility Design: Functions as both a metal stud and wood stud combo anchor, providing versatile installation options across different wall construction types.
  • Precise Dimensions: Measures 10" in length and 1-1/2" in width, delivering consistent fit and coverage for standard commercial door frame applications.
  • Heavy-Gauge Steel Construction: Fabricated from 18-gauge (.050) steel for robust structural integrity and long-lasting performance in demanding commercial environments.
  • Contractor-Friendly Pack Quantity: Available in a shelf pack of 50 units, making it efficient and cost-effective for multi-door projects and high-volume installations.
  • Commercial-Grade Quality: Designed and rated for commercial applications, ensuring compliance with professional installation standards for door trim and accessories.

Technical Specifications

  • Subcategory: Filler Plates
  • Product Group: Door Trim and Accessories
  • Product Subgroup: Filler Plates, Lock Adapters and Wrap Arounds
  • Commercial/Residential: Commercial
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Don-Jo 534 MWA?

Don-Jo 534 MWA Metal-Wood Stud Combo Anchors deliver professional-grade reliability through heavy-duty 18-gauge (.050) steel construction, ensuring consistent performance across both metal and wood stud installations. Engineered for demanding commercial applications, these anchors provide the structural dependability that contractors and installers require on every project.

Product Specs

Subcategory:
Filler Plates
Product Group:
Door Trim and Accessories
Product Subgroup:
Filler Plates, Lock Adapters and Wrap Arounds
Commercial/Residential:
Commercial
Product Type:
Metal-Wood Stud Combo Anchor
Product Model:
534 MWA
Product Category:
Door Trim and Accessories
Product Substrate:
Steel
Department:
Door Hardware

Don-Jo 534-MWA – Frequently Asked Questions

1) What does a Don-Jo 534 MWA combo anchor actually do, and where does it go in the wall?
The 534 MWA is a frame anchor, not a plate you see after the job is done. It ties a hollow metal door frame back into the stud behind it, and the same part works whether that stud is metal or wood, which is where the combo name comes from. It's 10 inches long by 1-1/2 inches wide in 18-gauge (.050) steel, so it spans the frame return and picks up the stud. It buries in the wall cavity, so finish isn't a factor.
2) Do I need a different anchor for wood stud walls than for metal stud walls?
Not with the 534 MWA. One anchor covers both, so a contractor framing a job with a mix of metal stud partitions and wood stud walls orders one part number instead of two. That matters most on renovation work where you find wood framing behind older openings and steel studs in the newer partitions, and you don't want two boxes of anchors on the truck.
3) Is the Don-Jo 534 the same thing as a wrap around plate or a filler plate?
No, and it's an easy mix-up because they sit near each other in the catalog. A wrap around plate covers damage around a bore on the door face and a filler plate closes an unused prep, both visible on the finished door. The 534 MWA is structural and hidden, it fastens the frame to the stud inside the wall. If you're patching a chewed-up lock area on a door face, this is the wrong part.
4) Is the Don-Jo 534 MWA anchor sold individually or in a box?
Shelf pack of 50. That's the buying unit, so a job with 12 openings taking two or three anchors per jamb is covered by a single pack. Smaller landlords replacing one frame should expect to buy the full 50 rather than a single anchor.
5) Is 18 gauge heavy enough for a commercial door frame anchor?
18-gauge is .050 inch steel, and it's the working gauge for frame anchors on commercial openings, offices, schools, healthcare, retail, warehouses, and multi-tenant residential. The anchor carries the frame's connection to the structure, not the door's weight, which hangs on the hinge jamb reinforcement. Don-Jo rates the 534 MWA as a commercial part.
6) Which Don-Jo model number do I ask for on the metal-wood combo stud anchor?
534 MWA is the model, from Don-Jo. Ten inches by 1-1/2 inches, 18 gauge. Distributors should note the MWA suffix is the combo metal-and-wood designation, so it's the identifier that separates this from Don-Jo's single-application anchors.
