Drill Bit HD Cobalt St 135d SplPt 15/32" 5-3/4" YLW (1pc)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Pack Type:
- Pouch
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
Metallics HSSC26E – Frequently Asked Questions
1) What size hole does the Metallics HSSC26E cobalt drill bit cut?
The HSSC26E is a 15/32 inch diameter bit with an overall length of 5-3/4 inches. That 15/32 size is the common tap-drill step just under 1/2 inch, so it is the bit reached for when a 1/2 inch hole would be too loose for the fastener or thread.
2) Will a cobalt drill bit cut stainless steel and hardened metal, or do I need carbide?
Cobalt is the right call for stainless, hardened steel, and cast iron. The HSSC26E is a heavy duty cobalt bit, and cobalt holds its edge at the higher temperatures those materials generate, where plain high speed steel burns up. Carbide only becomes necessary for masonry or abrasive material, and it is far more brittle in a hand drill.
3) What does the 135 degree split point on this Metallics bit do on the job?
A 135 degree split point self centers, so the HSSC26E starts without walking and without a center punch. That matters when you are drilling vertically into strut, panel enclosures, or a beam flange overhead where you cannot easily lay out and punch a mark first.
4) Is the HSSC26E long enough to drill through strut, angle iron, or a stacked assembly?
Overall length is 5-3/4 inches, which is a standard jobber length for a 15/32 bit. That gives usable flute depth for strut, angle, plate, and typical stacked steel, but it is not an extended aircraft-length bit, so deep reach-through work behind an obstruction needs a longer bit.
5) How many drill bits come in a Metallics HSSC26E order, and how is it packaged?
One bit per order, supplied in a pouch rather than a plastic index case or bulk carton. If you are stocking a van or an MRO crib and want a spare on the shelf, order the quantity you need individually.
6) What part number do I order to reorder this 15/32 cobalt bit?
Order Metallics part number HSSC26E. That one number covers the 15/32 inch, 5-3/4 inch cobalt straight shank split point bit, there are no finish or length options to specify.
7) Why is this Metallics bit yellow, and does the coating affect how it drills?
The yellow finish on the HSSC26E is how Metallics identifies its cobalt bits, so it is quick to pick out of a mixed pouch or drawer from plain bright high speed steel. It does not change the cutting geometry, the 135 degree split point and cobalt body do the work.
