Product Specs
- Amperage Rating:
- 200A
- Certifications:
- UL Listed
- Coil Voltage:
- 120 V, 60 Hz
- Contact Rating:
- 200 A
- Number Of Poles:
- Ten-pole
- Operation:
- Magnetically latched
- Product Height:
- 6.88 IN
- Product Length Depth:
- 12.38 IN
- Product Weight:
- .01 LB
- Product Width:
- 12.38 IN
- Series:
- A202 Series
- Department:
- Electrical
- Product Type:
- Lighting contactors
- Product Details:
- Lighting contactors
B-LINE A202K4GAM – Frequently Asked Questions
1) How many lighting circuits can the Eaton A202K4GAM lighting contactor switch?
Ten. The A202K4GAM is a ten-pole contactor rated 200 A per pole, so it can switch up to ten separate lighting circuits at that rating from one enclosure or panel position.
2) What control voltage does the A202 lighting contactor coil need?
120 V, 60 Hz. Your control wiring, time clock, photocell, or building automation relay contact has to switch 120 VAC to operate it. If your control circuit is 24 V or 277 V, this is the wrong coil.
3) Is the A202K4GAM mechanically held or does the coil stay energized?
It is magnetically latched, so the coil is only pulsed to change state and does not stay energized to hold the contacts. That means no continuous coil draw, no coil hum in an occupied space, and the contacts hold their last position through a control power interruption. If you want the load to drop out automatically when control power is lost, use an electrically held contactor instead.
4) What control does a magnetically latched lighting contactor need at the panel?
Because the A202 is a latching type, it needs momentary control, not a maintained contact: a momentary pulse on the ON coil and a separate pulse on the OFF side. A time clock or lighting relay panel with a two-wire or three-wire momentary output works; a simple maintained toggle switch is intended for electrically held contactors.
5) Can I use the A202K4GAM to switch a 200 amp lighting load?
Yes. Each pole carries a 200 A rating, and the amperage rating on the unit is 200A, so it is sized for large parking lot, warehouse high bay, or site lighting branch circuits rather than small office zones.
6) Does the A202K4GAM come in an enclosure or is it an open contactor?
The A202K4GAM is ordered as the contactor itself, model A202K4GAM, for mounting in a panel or an enclosure you provide or specify separately. Confirm your enclosure interior will take the 12.38 by 12.38 inch footprint.
