B-LINE Dura-Blok Rooftop Support 5" x 6" x 20.2" 1000 lbs Cast Iron with Electro-Plated Finish
Heavy-Duty Rooftop Equipment Support Solution
The B-LINE Dura-Blok rooftop support delivers reliable structural support for rooftop equipment installations with its robust cast iron construction and 1000 lbs load capacity. This professional-grade support block features precise dimensions of 5" height, 6" length, and 20.2" width, providing stable mounting platform for HVAC units, electrical equipment, and other rooftop installations. The electro-plated finish ensures long-lasting corrosion resistance in outdoor environments.
Professional Features & Benefits
- 1000 lbs Load Capacity: Supports heavy rooftop equipment installations with confidence and structural integrity
- Cast Iron Construction: Provides exceptional durability and strength for long-term outdoor performance
- Electro-Plated Finish: Delivers superior corrosion resistance and extended service life in harsh weather conditions
- Precision Dimensions: 5" x 6" x 20.2" sizing ensures proper fit and optimal load distribution
- Professional Grade Design: Engineered for commercial and industrial rooftop applications requiring reliable support
- B-LINE Quality: Trusted brand reputation for structural support solutions in electrical and mechanical systems
Technical Specifications
- Certifications: Contact Manufacturer
- Department: Electrical
- Load Capacity: 1000 lbs
- Material: Cast iron
- Product Finish: Electro-plated
- Product Group: Fasteners
- Product Height: 5 in
- Product Length Depth: 6 in
- Product Subgroup: Washers / Nuts / Bolts / Screws
- Product Type: Channel Nut
- Product Weight: 10.63 lb
- Product Width: 20.2 in
Professional Applications
- Commercial HVAC Equipment Support
- Industrial Rooftop Installations
- Electrical Equipment Mounting
- Mechanical System Support
- Multi-Unit Building Applications
- Professional Construction Projects
- Maintenance and Retrofit Applications
Why Choose B-LINE Quality?
B-LINE delivers trusted structural support solutions with proven cast iron construction and electro-plated finish for reliable long-term performance. The precision-engineered Dura-Blok rooftop support provides professional-grade reliability for demanding commercial and industrial applications requiring dependable equipment mounting solutions.
Manufacturer Resources
Product Specs
- Certifications:
- Contact Manufacturer
- Load Capacity:
- 1000 lbs
- Product Height:
- 5 in
- Product Length Depth:
- 6 in
- Product Weight:
- 10.63 lb
- Product Width:
- 20.2 in
- Product Type:
- Channel Nut
- Department:
- Electrical
- Product Group:
- Fasteners
- Product Subgroup:
- Washers / Nuts / Bolts / Screws
- Product Finish:
- Electro-plated
- Product Material:
- Cast iron
B-LINE DB20 – Frequently Asked Questions
1) How much weight can a B-LINE Dura-Blok DB20 rooftop support hold?
The Dura-Blok DB20 block carries a 1000 lbs load capacity. That is the rating for the block itself, so on a run of pipe, duct or conduit you size the number of blocks and the spacing between them to keep each one under that figure rather than leaning on a single support. For heavier packaged equipment, add blocks along the run instead of concentrating the load on one point.
2) Do I have to penetrate the roof membrane to install a Dura-Blok DB20?
No penetration is involved. The DB20 is a free-standing block that sits on the roof surface and holds the load by its own mass and bearing area, which is why it is used on membrane and built-up roofs where drilling into the deck would void the roofing work. Its 5 inch height lifts the supported pipe or equipment clear of standing water and lets a roofer flash and re-cover underneath later.
3) Will a Dura-Blok DB20 hold up outdoors on an exposed roof?
Cast iron with an electro-plated finish is what the DB20 is built from, so it is made for continuous outdoor exposure on a roof deck rather than for interior mechanical rooms only. The plating is the corrosion barrier; keep it intact and avoid grinding or cutting the block on site.
4) How heavy is a single Dura-Blok DB20 to carry up to the roof?
Each DB20 weighs 10.63 lb, so one person can hand-carry two or three up a ladder or hoist a pallet of them without rigging. That matters when you are laying out a long conduit or refrigerant line run and need a dozen blocks placed by hand across a finished membrane.
