B-Line BKB38-094-120 Eaton series hanging system, KwikWire accessory features, Assembly only, no more sawing, filing, fixing nuts, Bolt 3⁄8-16 thread termination, 3/32" wire max, 120" wire length

It terminates in a 3/8-16 bolt, so it threads straight into 3/8-16 tapped fittings, strut nuts, or fixture hangers already on the job. That is the standard 3/8-16 coarse thread used on most commercial electrical and lighting supports, so no adapter is needed if the receiving component is tapped 3/8-16.

That is the point of the KwikWire system. It is made to install without drilling into the existing structure, so it suits tenant fit-outs, retrofits in occupied space, and post-tension or historic decks where you cannot core or drill. Where you have clear access and permission to drill, threaded rod is still the cheaper support; the wire system earns its place when drilling is off the table or when you are hanging many drops fast.

It is cULus Listed, which covers both US and Canadian requirements, so it can be specified on jobs on either side of the border. The department classification is electrical, which is where these hanging systems are typically used for lighting, cable tray, and raceway support.

It ships as a complete assembly: 120 inches of 3/32 wire with the gripper and the 3/8-16 bolt termination already fitted. You still supply the anchorage at the structure end and whatever the 3/8-16 bolt threads into at the load end.

Wire diameter is 0.09375 inch, which is 3/32 inch. If your gripper stock or replacement cable is a different gauge, it will not seat correctly in this gripper, so match the 3/32 size when ordering spares.

Order B-Line BKB38-094-120. The number breaks down as the bolt (B) with 3/8-16 thread (KB38), 0.094 wire (094), and 120 inch wire length (120), so sibling part numbers in the family differ mainly by termination type, wire size, and length.

Each assembly is listed at 3.472 lb. Worth factoring in when you are pricing out a large lighting package with several hundred drops.
