Eaton B-Line series lock latch and handle, NEMA 12 rated, Bright plated, Handle kits used for 3-pt field modification, Single-door enclosure padlock handle kits, Locks, latches, inserts, and handles, handles
Manufacturer Resources
Product Specs
- Application:
- Handle kits used for 3-pt field modification
- Certifications:
- UL Listed
- Degree Of Protection:
- NEMA 12
- Finish Color:
- Bright plated
- Product Category:
- Locks, latches, inserts, & handles, handles
- Product Height:
- 20 in
- Product Length Depth:
- 20 in
- Product Weight:
- 2.865 lb
- Product Width:
- .43 in
- Department:
- Electrical
- Product Group:
- Enclosures & Boxes
- Product Subgroup:
- Locks & Handles
- Product Type:
- Single-door enclosure padlock handle kits
- Product Details:
- Single-door enclosure padlock handle kits
- Product Style:
- Slotted cover screw
B-LINE 25345 A20 – Frequently Asked Questions
1) What is the Eaton B-Line 25345 A20 handle kit used for?
It's a padlock handle kit for a single-door electrical enclosure, sold for 3-point field modification. In other words, you use it to convert or upgrade an existing single-door enclosure to a 3-point latching handle with padlocking capability, rather than replacing the whole box. The kit falls in the locks, latches, inserts and handles family, and it uses a slotted cover screw style.
2) Will the B-Line 25345 A20 handle kit keep a NEMA 12 enclosure rating?
Yes. The 25345 A20 lock latch and handle is rated NEMA 12, so it's built for the dust, falling dirt and dripping non-corrosive liquid duty typical of indoor industrial panels. It is also UL Listed. Keep in mind the enclosure itself must be NEMA 12 construction for the assembly to hold that rating.
3) Is the B-Line 25345 A20 handle kit suitable for a washdown or outdoor enclosure?
No. It is a NEMA 12 rated handle, which covers indoor dust and dripping liquids only. For hosedown, washdown or wet outdoor locations you need hardware rated NEMA 4 or 4X instead. Putting a NEMA 12 handle on a 4X enclosure compromises the enclosure rating.
4) How long is the B-Line 25345 A20 handle kit, and how much does it weigh?
The kit is listed at 20 inches height and 20 inches length/depth, with a .43 inch width, and it weighs 2.865 lb. That 20 inch dimension is what matters when you're checking whether the linkage suits the door height on the enclosure you're modifying.
5) Can I padlock the B-Line 25345 A20 handle for lockout/tagout?
Yes, it's a padlock handle kit, so the handle accepts a padlock to secure the enclosure door shut. Combined with 3-point latching, one padlocked handle holds the door at three points instead of one.
6) Will this B-Line handle kit work on a double-door enclosure?
No. The 25345 A20 is a single-door enclosure handle kit. Two-door enclosures use different hardware, typically a handle on the active leaf plus separate latching for the inactive leaf, so specify a two-door kit for that opening.
