Eaton B-Line series other enclosure accessories, NEMA 4, Black, Type 4 - small security insert (4mm socket hex)
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Degree Of Protection:
- NEMA 4
- Finish Color:
- Black
- Product Height:
- 4 in
- Product Length Depth:
- 4 in
- Product Weight:
- .023 lb
- Product Width:
- 4 in
- Department:
- Electrical
B-LINE 4MT4HXLKBM – Frequently Asked Questions
1) What tool do I need to open an enclosure fitted with the B-Line 4MT4HXLKBM security insert?
A 4mm hex socket key. The 4MT4HXLKBM is a small security insert that converts the enclosure latch to a 4mm socket hex drive, so only someone carrying that key opens the door. Stock a couple of 4mm hex keys with the techs who service the panel, since a standard screwdriver or quarter-turn tool will not engage it.
2) Will a security insert compromise the NEMA 4 rating of my wash-down enclosure?
No. The 4MT4HXLKBM insert is rated NEMA 4 itself, so it is intended for the same hosedown and driving-rain duty as a Type 4 enclosure. It is also UL Listed.
3) Is this a complete lock or just an insert for an existing B-Line latch?
It is an insert, not a standalone lock. The Eaton B-Line Type 4 small security insert drops into the existing latch position on a B-Line enclosure to give it a 4mm hex drive. You still need the enclosure and its latch hardware; this part only changes what tool opens it.
4) Should I use a hex security insert or a keyed lock on outdoor control enclosures?
A 4mm hex insert like the 4MT4HXLKBM is the simpler choice when you want to keep casual hands out of a fleet of panels without managing keys: every tech carries one 4mm key and it opens every box you have standardized. A keyed cylinder makes sense when you need to restrict access between crews or log who has a key. The hex insert also holds NEMA 4, so it suits outdoor and wash-down locations.
5) What color is the B-Line 4MT4HXLKBM insert, and will it match a black enclosure?
Black finish, so it blends with black powder-coated B-Line enclosures. On a gray or stainless box it will read as a dark accent at the latch.
