B-Line N4236P Eaton series pan...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,282.38
B-Line N4236P Eaton series panel enclosure, NEMA 3R, ANSI 61 gray painted, Protects against rain, sleet and ice formation, Galvanized steel, Wall mounting, Panel enclosures, Type 3r large continuous hinge cover, 42" X 36" panel

B-Line N4236P Eaton series panel enclosure, NEMA 3R, ANSI 61 gray painted, Protects against rain, sleet and ice formation, Galvanized steel, Wall mounting, Panel enclosures, Type 3r large continuous hinge cover, 42" X 36" panel

(No reviews yet) Write a Review

Model: N4236P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,282.38
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series panel enclosure, NEMA 3R, ANSI 61 gray painted, Protects against rain, sleet and ice formation, Galvanized steel, Wall mounting, Panel enclosures, Type 3r large continuous hinge cover, 42" X 36" panel

Manufacturer Resources

Product Specs

Application:
Protects against rain, sleet and ice formation
Certifications:
UL Listed
Degree Of Protection:
NEMA 3R
Finish Color:
ANSI 61 gray painted
Mounting Method:
Wall
Product Category:
Panel enclosures
Product Height:
38.87 in
Product Length Depth:
32.875 in
Product Weight:
38.194 lb
Product Width:
32.87 in
Department:
Electrical
Product Group:
Enclosures & Boxes
Product Subgroup:
Covers
Product Type:
Type 3r large continuous hinge cover
Product Details:
Type 3r large continuous hinge cover
Product Material:
Galvanized steel
Product Length:
32.875 in

B-LINE N4236P – Frequently Asked Questions

1) Can the B-Line N4236P enclosure be installed outdoors?
Yes, within the limits of NEMA 3R. The N4236P is rated NEMA 3R and protects the contents against rain, sleet and ice formation, so it suits outdoor wall locations like a pump house wall, rooftop, or exterior utility run. NEMA 3R does not cover hose-directed water or windblown dust; if the enclosure will be washed down or sits in a dusty yard, step up to a 4 or 4X rated box instead.
2) Is the N4236P a complete enclosure or just a cover?
The N4236P is the Type 3R large continuous hinge cover for a 42 x 36 inch panel enclosure in the Eaton B-Line series. It is the hinged cover portion, not a boxed enclosure with a back. Order it to match the 42 x 36 panel body you already have or are buying alongside it.
3) Will the gray finish on this B-Line cover match the rest of my switchgear?
The finish is ANSI 61 gray paint, which is the standard gray used across most industrial control panels, switchgear, and enclosure lines. If your existing gear is ANSI 61, the N4236P cover will read as the same color. Underneath the paint the material is galvanized steel.
4) How does this B-Line enclosure mount, and does it stand on the floor?
Wall mounting only. The N4236P is part of a wall-mount panel enclosure assembly, not a free-standing or floor-mount cabinet. For a floor installation you would need a free-standing enclosure line with a base, not this cover.
5) What part number do I order for the 42 x 36 Type 3R hinged cover?
The manufacturer part number is N4236P from Eaton's B-Line series. It is a single configuration, no finish or size options to specify, so the number alone gets you the 42 x 36 inch Type 3R continuous hinge cover in ANSI 61 gray.
