B-Line Eaton series panels and...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,962.17
B-Line Eaton series panels and panel accessories, 1, White powder coated, Steel, Panels and panel accessories, Fits 54" X 42" enclosures, Large flan

B-Line Eaton series panels and panel accessories, 1, White powder coated, Steel, Panels and panel accessories, Fits 54" X 42" enclosures, Large flan

(No reviews yet) Write a Review

Model: AW5442P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,962.17
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series panels and panel accessories, NEMA 1, White powder coated, Steel, Panels and panel accessories, Fits 54" X 42" enclosures, Large NEMA flanged panels, 10 gauge

Manufacturer Resources

Product Specs

Certifications:
UL Listed
Degree Of Protection:
NEMA 1
Finish Color:
White powder coated
Product Category:
Panels & panel accessories
Product Height:
49.87 in
Product Length Depth:
37.875 in
Product Weight:
76.289 lb
Product Width:
37.875 in
Special Features:
Fits 54" X 42" enclosures
Department:
Electrical
Product Style:
Panel
Product Material:
Steel

B-LINE AW5442P – Frequently Asked Questions

1) Which enclosure size does the Eaton B-Line AW5442P back panel fit?
The AW5442P flanged panel is built for 54 x 42 inch enclosures. It is the inner mounting panel, not the enclosure itself, so the box has to already be a 54 x 42 size for the panel to land on the mounting studs.
2) What are the actual panel dimensions on the B-Line AW5442P?
Measured as a panel, it is 49.87 in in height and 37.875 in in width, with a 37.875 in length/depth figure on the same record. Those are the usable mounting-surface numbers, smaller than the 54 x 42 enclosure it drops into, which is normal for a back panel that sits inside the box.
3) Is the AW5442P panel UL Listed, and what NEMA rating does it carry?
It is UL Listed and carries a NEMA 1 designation, which is indoor general purpose, protecting against incidental contact and falling dirt. NEMA 1 is not a washdown, dust-tight, or outdoor rating, so for wet or dirty locations the enclosure and panel combination has to be specified to a higher type.
4) How heavy is the AW5442P panel, and can one person hang it?
It weighs 76.289 lb. That is a two-person lift into a wall-mounted enclosure, and in 10 gauge steel it will not flex much while you maneuver it, so plan for a helper or a panel lift rather than trying to set it alone.
5) Is the Eaton B-Line 54 x 42 flanged panel steel or aluminum, and what is the finish?
Steel, in 10 gauge, finished in white powder coat. The white face is the standard choice for control panels because it reflects light inside the enclosure and makes wire labels and component legends easier to read during troubleshooting.
6) What is a flanged panel and why choose it over a flat back panel?
A flanged panel has its edges bent, which stiffens the sheet and sets the mounting surface off the enclosure back wall so wire can route behind it. On a large 54 x 42 opening that stiffness matters, since a flat sheet of that span loaded with contactors and drives would oil-can. The AW5442P is the large flanged version in 10 gauge steel.
7) Does the AW5442P come with the enclosure or any mounting hardware?
It is the panel alone, an accessory for a 54 x 42 enclosure you already have or are ordering separately. Order the enclosure, and any panel mounting studs or clips it requires, under their own part numbers.
8) What part number do I quote to standardize replacement panels across a plant?
Eaton B-Line AW5442P is the number to put on the requisition. One model covers the 54 x 42 NEMA 1 large flanged panel in white powder coated 10 gauge steel, so there are no finish or gauge suffixes to sort out when a maintenance group reorders.
