B-Line Eaton series strut chan...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$14,422.10
B-Line Eaton series strut channel, 3.25" channel height, 240" channel length, 1.62" channel width, Steel, 12 Gauge, B11 channel type, DURA GREEN

B-Line Eaton series strut channel, 3.25" channel height, 240" channel length, 1.62" channel width, Steel, 12 Gauge, B11 channel type, DURA GREEN

(No reviews yet) Write a Review

Model: B11-240GRN
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$14,422.10
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series strut channel, 3.25" channel height, 240" channel length, 1.62" channel width, Steel, 12 Gauge, B11 channel type, DURA GREEN

Manufacturer Resources

Product Specs

Certifications:
Not Applicable
Channel Type:
B11
Material Gauge:
12 Gauge
Product Height:
3.25 in
Product Length Depth:
240 in
Product Weight:
61 lb
Product Width:
1.62 in
Department:
Electrical
Product Finish:
DURA GREEN
Product Material:
Steel

B-LINE B11-240GRN – Frequently Asked Questions

1) What size is the B-Line B11 strut channel, and will it fit a standard 1-5/8 inch strut fitting?
The B-Line B11 channel measures 1.62 in wide by 3.25 in high, so the open face is the usual 1-5/8 inch strut width and standard 1-5/8 inch strut nuts, clamps and fittings seat in it. The 3.25 in height is a double-height (back-to-back style) profile rather than the common 1-5/8 x 1-5/8 section, so anything that wraps the outside of the channel, like post bases or clamp straps sized for a 1-5/8 inch deep channel, will not fit.
2) Does the B11-240GRN strut channel come with nuts, bolts or brackets?
No. B11-240GRN is the bare channel only, a 240 in stick in 12 gauge steel. Strut nuts, spring nuts, threaded rod, end caps and any fittings are ordered separately, and you want 1-5/8 inch series hardware to match the channel face.
3) What gauge steel is B-Line B11 strut, and is it heavy enough for trapeze hangers?
12 gauge steel, which is the standard heavy-duty strut thickness, combined here with the 3.25 in deep B11 profile. That combination is what electricians and mechanical contractors use for trapeze supports spanning between structural members rather than light single-conduit hangers.
4) What is the exact part number to order this green 20 foot B-Line strut?
Order Eaton B-Line part B11-240GRN. The suffix breaks down as B11 profile, 240 in length, GRN for the DURA GREEN finish, so a different length or finish in the same profile carries a different number.
