Eaton B-Line Universal Shelf Bracket
Professional Strut Channel Mounting Support System
The Eaton B-Line Universal Shelf Bracket delivers exceptional structural support and installation efficiency for versatile shelf mounting applications in strut channel systems. This steel construction universal bracket provides reliable mounting solutions designed for professional electricians, mechanical contractors, and facility installers, offering the proven strength and versatile mounting capabilities that professionals trust from the industry leader in strut channel systems.
Professional Features & Benefits
Structural Performance Excellence
- Steel Construction - Provides exceptional structural integrity and long-lasting durability for demanding commercial and industrial mounting applications
- 4 Inch Height Design - Offers optimal vertical clearance and mounting flexibility for various shelf configurations and equipment installations
- 4 Inch Length Profile - Delivers comprehensive support coverage with professional-grade structural stability for reliable shelf mounting
- 1.78 Inch Width Configuration - Ensures proper strut channel compatibility while maintaining compact installation footprint
Installation & Mounting Efficiency
- Universal Design Compatibility - Accommodates multiple strut channel configurations and mounting scenarios for maximum installation versatility
- Lightweight .132 lb Construction - Facilitates easy handling and installation while maintaining structural performance standards
- Electro-Plated Zinc Finish - Provides superior corrosion resistance and environmental protection for long-term reliability
Professional Quality Standards
- B-Line Engineering Excellence - Manufactured to industry-leading quality standards with precision tolerances for consistent performance
- Professional Grade Materials - Steel construction ensures reliable structural performance in commercial and industrial environments
Technical Specifications
Height: 4 inches, Length: 4 inches, Width: 1.78 inches, Weight: .132 lb, Material: Steel construction, Finish: Electro-plated zinc coating, Product Type: Universal shelf bracket, Product Group: Mounting Hardware, Product Subgroup: Brackets, Certifications: Not Applicable
Installation & Usage
- Select appropriate strut channel location and verify structural support requirements for intended shelf load
- Position universal shelf bracket at desired mounting location ensuring proper alignment with strut channel
- Secure bracket to strut channel using appropriate fastening hardware for your specific installation requirements
- Verify bracket is properly seated and securely fastened before proceeding with shelf installation
- Install shelf or equipment platform ensuring even weight distribution across bracket support points
- Perform final inspection to confirm secure mounting and proper load distribution before placing equipment or materials
Professional Applications
Ideal for:
- Equipment Shelving Systems - Control panels, electrical equipment, and instrumentation mounting in commercial and industrial facilities
- Storage Solutions - Parts storage, tool organization, and material handling systems in maintenance and production areas
- Electrical Panel Support - Mounting platforms for electrical enclosures, junction boxes, and control equipment installations
- HVAC Equipment Platforms - Support brackets for HVAC controls, sensors, and auxiliary equipment mounting applications
- Industrial Workstations - Work surface support and equipment mounting in manufacturing and assembly environments
- Telecommunications Infrastructure - Equipment shelving for network hardware, communication devices, and cable management systems
- Laboratory Equipment Support - Instrument mounting and equipment platforms in research and testing facilities
- Maintenance Access Platforms - Service platforms and equipment access solutions for facility maintenance operations
Electro-Plated Zinc Finish Advantage
The electro-plated zinc finish provides exceptional corrosion resistance and environmental protection, making this bracket ideal for both indoor and outdoor installations. This professional-grade coating ensures long-term durability and maintains structural integrity in challenging environmental conditions, reducing maintenance requirements and extending service life.
Why Choose B-Line Quality?
B-Line's decades of structural support innovation and manufacturing excellence ensure this universal shelf bracket meets the demanding requirements of professional contractors, electricians, and facility managers. With industry-leading quality standards, precision engineering, and comprehensive compatibility with strut channel systems, B-Line delivers the reliable performance and structural integrity that professionals trust for critical mounting applications worldwide.
Manufacturer Resources
Product Specs
- Certifications:
- Not Applicable
- Finish:
- Electro-plated
- Material:
- Steel
- Product Height:
- 4 in
- Product Length Depth:
- 4 in
- Product Weight:
- .132 lb
- Product Width:
- 1.78 in
- Type:
- Universal shelf bracket
- Product Type:
- Universal shelf bracket
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Brackets
