Eaton B-Line Conduit 90 Degree Angle Plate 600 lb Load Capacity Aluminum with Hex Head Machine Screw

Eaton B-Line Conduit 90 Degree Angle Plate

Professional Aluminum Conduit Support System with Integrated Hardware

The Eaton B-Line Conduit 90 Degree Angle Plate delivers exceptional structural support and installation efficiency for conduit mounting applications requiring precise 90-degree positioning. This 600 lb load capacity aluminum angle plate provides reliable mounting solutions designed for professional electricians, mechanical contractors, and facility installers, offering the proven strength and versatile mounting capabilities that professionals trust from the industry leader in strut channel systems.

Professional Features & Benefits

Structural Performance Excellence

• 600 lb Load Capacity Rating - Engineered for heavy-duty conduit support applications with reliable structural performance and safety compliance
• Precision 90 Degree Angle Design - Ensures accurate conduit positioning and professional installation alignment for electrical system integrity
• Lightweight Aluminum Construction - Provides excellent strength-to-weight ratio while offering superior corrosion resistance for long-term durability
• Compact Profile Dimensions - 2.608" length x 1.25" width x 0.081" height design optimizes space utilization in tight installation environments

Installation Efficiency

• Integrated Hex Head Machine Screw - Includes combination recess hex head machine screw for streamlined installation and secure fastening
• Professional Mounting Hardware - Complete hardware package eliminates additional component sourcing and reduces installation time
• Versatile Adapter Design - Functions as reliable connector and adapter for various conduit support configurations

Technical Specifications

Load Capacity: 600 lbs | Material: Aluminum | Dimensions: 2.608" L x 1.25" W x 0.081" H | Weight: 0.15 lb | Product Type: Conduit 90 Degree Angle Plate | Special Features: Include combination recess hex head machine screw | Certifications: Not Applicable

Installation & Usage

1. Position the angle plate at the desired 90-degree conduit mounting location ensuring proper structural support alignment
2. Mark mounting hole locations using the plate as a template for accurate positioning
3. Secure the angle plate to the mounting surface using the included combination recess hex head machine screw
4. Verify the 90-degree angle orientation and load capacity requirements for the specific conduit installation
5. Attach conduit support hardware to the angle plate following manufacturer specifications
6. Perform final inspection to ensure secure mounting and proper load distribution

Professional Applications

Ideal for:

• Electrical Conduit Support Systems - Primary and secondary conduit routing with precise 90-degree directional changes
• Commercial Building Infrastructure - Office buildings, retail spaces, and institutional facility electrical installations
• Industrial Equipment Mounting - Manufacturing facilities requiring robust conduit support for machinery connections
• Mechanical System Integration - HVAC and process piping systems requiring structural conduit support
• Facility Maintenance Projects - Retrofit and upgrade applications for existing electrical infrastructure
• Data Center Installations - Critical facility power distribution and cable management systems
• Healthcare Facility Systems - Hospital and medical facility electrical infrastructure with stringent reliability requirements
• Educational Institution Projects - School and university electrical system installations and renovations

Aluminum Construction Advantage

The aluminum construction provides exceptional corrosion resistance for both indoor and outdoor applications while maintaining superior strength-to-weight performance. This material choice ensures long-term structural integrity in diverse environmental conditions, from humid industrial settings to temperature-variable commercial spaces, making it ideal for professional electrical contractors who demand reliable performance and extended service life.

Why Choose B-Line Quality?

B-Line's decades of structural support innovation and engineering excellence deliver the load-rated reliability and safety that electrical contractors, mechanical professionals, and facility managers trust worldwide. Our commitment to precision manufacturing, comprehensive testing, and industry-standard compatibility ensures that every angle plate meets the demanding requirements of professional installations while providing the versatile mounting solutions that streamline project completion and long-term system performance.
