Eaton BAB Thermal Magnetic Circuit Breaker 35A 10kAIC HACR Rated with Bolt-On Mounting

Eaton BAB Thermal Magnetic Circuit Breaker 35A 10kAIC HACR Rated with Bolt-On Mounting

Professional Industrial Circuit Protection with Quicklag Technology

The Eaton BAB Thermal Magnetic Circuit Breaker delivers reliable 35A circuit protection with 10kAIC interrupt rating and HACR certification for heating, air conditioning, and refrigeration applications. This industrial-grade Quicklag thermal-magnetic circuit breaker features bolt-on mounting and accommodates ring or spade lug terminals for versatile professional installations.

Professional Features & Benefits

• 35A Amperage Rating: Provides precise current protection for medium-duty electrical circuits and equipment loads.
• 10kAIC Interrupt Rating: Delivers reliable fault current interruption capability for industrial and commercial applications.
• HACR Certification: Specifically rated for heating, air conditioning, and refrigeration equipment protection with enhanced motor starting characteristics.
• Quicklag Thermal-Magnetic Technology: Combines thermal overload protection with magnetic short-circuit protection for comprehensive circuit safeguarding.
• Bolt-On Mounting: Ensures secure mechanical connection and reliable electrical contact in panel installations.
• Ring or Spade Lug Terminals: Accommodates multiple conductor connection methods for flexible wiring configurations.
• Non-Interchangeable Trip Type: Maintains consistent protection characteristics and prevents unauthorized trip setting modifications.

Technical Specifications

• Amperage Rating: 35 A
• Catalog Notes: HACR rated
• Circuit Breaker Type: BAB
• Interrupt Rating: 10 kAIC
• Item Quantity: 7
• Mounting Method: Bolt-on
• Product Details: Quicklag industrial thermal-magnetic circuit breaker
• Shunt Trip: 120-240V
• Terminals: Ring or spade lug
• Trip Type: Non-Interchangeable

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• HVAC Equipment Protection
• Industrial Motor Control Centers
• Commercial Refrigeration Systems
• Manufacturing Facility Distribution
• Process Equipment Protection
• Building Automation Systems
• Critical Infrastructure Applications

Why Choose Eaton Quality?

Eaton BAB circuit breakers deliver proven reliability with HACR certification and 10kAIC interrupt rating, ensuring dependable protection for critical electrical systems. The Quicklag thermal-magnetic technology and bolt-on mounting provide professional-grade performance for demanding industrial and commercial applications.
