Eaton boot
Manufacturer Resources
Product Specs
- Compliances:
- RoHS Compliant
- Design Type:
- Boot
- Product Height:
- 3.375 IN
- Product Length Depth:
- 6.938 IN
- Product Weight:
- 1.05 LB
- Product Width:
- 3.61 IN
- Special Features:
- Flexible and easy to apply to connector, cord hole opening can be cut away for large diamter cords
- Used With:
- 20A and 30A four-wire and five wire industrial locking devices
- Department:
- Electrical
- Product Type:
- Boot
- Product Details:
- Boot
- Product Color:
- Yellow
- Product Material:
- Neoprene
B-LINE BL2 – Frequently Asked Questions
1) What plugs and connectors does the B-Line BL2 boot fit?
The BL2 is made for 20A and 30A four-wire and five-wire industrial locking devices. If your plug or connector is a two-wire or three-wire locking device, or a straight-blade cord cap, this is not the boot for it.
2) Will the BL2 boot accept a large diameter cord?
Yes. The cord hole opening on the BL2 can be cut away to pass a larger diameter cord, so a heavy portable feeder cord is not a problem. The neoprene body is flexible and goes on over the connector by hand.
3) What is the B-Line BL2 boot made of, and is neoprene suitable for a wet or outdoor temporary power setup?
Neoprene is the material. It stays flexible so the boot can be stretched over the connector body, and it is the usual choice for protective boots on portable and temporary power connections where the device gets handled, dragged, and exposed. The BL2 is also RoHS compliant.
4) How big is the BL2 boot? I need to know it will clear the adjacent device in a panel.
The BL2 measures 3.375 in height, 6.938 in length/depth, and 3.61 in width, and weighs 1.05 lb. Use the 6.938 in length as the run off the face of the connector when you are checking clearance behind or beside a mounted device.
5) What is the exact part number to order for the B-Line yellow locking device boot?
Order B-Line BL2. It is a single-model item, so there is no finish, size, or handing choice to specify, and the MPN on the box reads BL2.
6) Does the BL2 boot come with the plug or connector, or is it just the boot?
Just the boot. The BL2 is the neoprene protective cover alone, applied over a 20A or 30A four-wire or five-wire locking device you already have or are buying separately. No plug, connector, or clamp is part of it.
7) Is the B-Line BL2 boot yellow, and does the color matter for jobsite use?
Yellow is the color. On temporary power and portable cord assemblies that high-visibility yellow makes the connection easy to spot on a floor or in a trench, which is the practical reason boots like this are not black.
