Eaton Bussmann series high speed square body fuse, 1250V (IEC), 1300V (UL), 100A, 200 kAIC, Other, Fuse, Blade end X blade end, Class aR, DIN 43 620 - 170M3262
Manufacturer Resources
Product Specs
- Amperage Rating:
- 100A
- Amperage Rating Numeric:
- 100 A
- Application:
- semiconductor protection
- Certifications:
- IEC Rated
- Class:
- Class aR
- Clearing I2t :
- Clearing at 660V: 2450
- Clearing Loss:
- 21
- Compliances:
- CE Marked
- Connection:
- Blade end X blade end
- Fuse Indicator:
- Other
- Fuse Shape:
- square body with centre-bolted tags (slotted)
- Insulated Metal Gripping Lugs Imgl :
- No
- Interrupt Rating:
- 200 kAIC
- Mounting:
- DIN 43 620
- Packaging Type:
- Standard
- Pre Arc I2t :
- Current pre-arc: 360
- Product Height:
- 58 MM
- Product Length Depth:
- 104 MM
- Product Weight:
- 71 G
- Product Width:
- 45 MM
- Type:
- Fuse
- Utilization Category:
- aR (accompanied semiconductor protection)
- Voltage Rating:
- 1250V (IEC), 1300V (UL)
- Voltage Rating Numeric:
- 690 V
- Voltage Type:
- AC
- Product Group:
- Fuses
- Department:
- Electrical
- Product Subgroup:
- Other Fuses
- Product Type:
- Fuse
