Bussmann Time Delay Fuse LP-CC Series 5A 600VAC/150VDC Class CC Ferrule End Current Limiting

Bussmann Time Delay Fuse LP-CC Series 5A 600VAC/150VDC Class CC Ferrule End Current Limiting

Professional-Grade Current Limiting Circuit Protection

The Bussmann LP-CC Series Time Delay Fuse delivers superior electrical protection and circuit safety for specialized circuits and industrial control applications. This Class CC time delay fuse features dual element current-limiting technology designed for electrical contractors, industrial facilities, and commercial installations, providing the reliable overcurrent protection and industry-leading safety that electrical professionals demand.

Professional Features & Benefits

Current Limiting Protection

• Dual Element Design - Provides time delay characteristics for motor starting while offering fast response to short circuits
• 200 kAIC Interrupt Rating at 600VAC - Superior fault current clearing capability for high-energy electrical systems
• Current Limiting Technology - Reduces let-through energy and peak current to protect downstream equipment
• Rejection Style Construction - Prevents installation of incorrect fuse types for enhanced electrical safety

Safety & Standards Compliance

• Class CC Classification - Meets stringent NEC requirements for branch circuit and feeder protection
• CE Marked Certification - Ensures compliance with international electrical safety standards
• Non-Indicating Design - Professional-grade construction for reliable operation without visual indication

Technical Specifications

5A amperage rating, 600VAC/150VDC voltage rating, 200 kAIC interrupt rating at 600VAC and 20 kAIC at 150VDC, Class CC classification, ferrule end connections, 1.5" x 0.41" x 0.41" dimensions, 0.15 lb weight, 12 second response time at 200% rated current, melamine tube construction with dual element time delay characteristics.

Installation & Setup

1. Verify power is completely disconnected and use proper lockout/tagout procedures before installation
2. Confirm fuse holder is rated for Class CC fuses and 600VAC operation
3. Check that ferrule end connections are clean and properly sized for secure contact
4. Install fuse ensuring rejection style features align correctly with fuse holder
5. Verify proper torque on connections per manufacturer specifications
6. Test installation with appropriate electrical testing equipment before energizing circuit

Professional Applications

Ideal for:

• Motor Protection Circuits - Time delay characteristics accommodate motor starting currents while protecting against overloads
• Industrial Control Systems - Specialized circuit protection for automation and process control equipment
• Transformer Secondary Protection - Current limiting design protects transformers from fault conditions
• Control Panel Applications - Compact Class CC design fits standard industrial control enclosures
• Lighting Circuit Protection - Handles inrush currents while providing reliable overcurrent protection
• Power Distribution Systems - Branch circuit protection in commercial and industrial electrical panels
• Electronic Equipment Protection - Current limiting technology protects sensitive electronic loads
• Feeder Circuit Applications - Meets NEC requirements for feeder protection in electrical distribution systems

Current Limiting Technology Advantage

Bussmann's advanced current limiting technology significantly reduces let-through energy during fault conditions, protecting downstream equipment from damaging thermal and magnetic stresses. The dual element design provides excellent time-current characteristics, allowing temporary overloads while quickly clearing dangerous fault currents. This selective coordination capability ensures only the fuse closest to the fault opens, maintaining power to unaffected circuits.

Why Choose Bussmann Quality?

Bussmann demonstrates unwavering commitment to electrical safety through rigorous testing, CE marking compliance, and adherence to Class CC standards. Every LP-CC series fuse undergoes comprehensive quality control to ensure reliable overcurrent protection, consistent time-delay characteristics, and dependable current limiting performance. Professional electrical contractors trust Bussmann for critical circuit protection applications where safety, reliability, and NEC compliance are essential for successful installations.
