Bussmann Time Delay Fuse LP-CC Series 6A 600VAC/150VDC Class CC Current Limiting Ferrule End

Bussmann Time Delay Fuse LP-CC Series 6A 600VAC/150VDC Class CC Current Limiting Ferrule End

Professional-Grade Current Limiting Circuit Protection

The Bussmann LP-CC Series Time Delay Fuse delivers superior electrical protection and circuit safety for motor circuits, control panels, and industrial applications. This Class CC current limiting fuse features rejection-style design with 200 kAIC interrupt rating at 600VAC, designed for electrical contractors, industrial facilities, and commercial installations, providing the reliable overcurrent protection and industry-leading safety that electrical professionals demand.

Professional Features & Benefits

Current Limiting Protection

• 200 kAIC Interrupt Rating at 600VAC - Superior fault current clearing capability for high-energy electrical systems
• 20 kAIC at 150VDC - Reliable DC circuit protection for control and power applications
• Current Limiting Technology - Reduces let-through energy and protects downstream equipment from damage
• Time Delay Characteristics - Allows temporary overloads while providing fast fault clearing

Safety & Standards Compliance

• Class CC Rejection Style - Prevents installation of incorrect fuse types for enhanced safety
• CE Marked Compliance - Meets international electrical safety standards
• Non-Indicating Design - Professional-grade construction for reliable operation

Technical Specifications

6 ampere rating, 600VAC/150VDC voltage rating, 200 kAIC interrupt rating at 600VAC, 20 kAIC at 150VDC, Class CC rejection style, ferrule end connections, melamine tube construction, 1.5" x 0.41" x 0.41" dimensions, 0.15 lb weight, time delay response characteristics

Installation & Setup

1. Verify power is OFF and use proper lockout/tagout procedures before installation
2. Confirm fuse holder accepts Class CC rejection-style fuses
3. Insert fuse ensuring proper ferrule end contact with fuse clips
4. Verify secure mechanical connection and proper fuse seating
5. Test circuit operation and verify proper overcurrent protection
6. Document installation per NEC requirements and facility standards

Professional Applications

Ideal for:

• Motor Protection Circuits - Time delay allows motor starting currents while protecting against overloads
• Control Panel Applications - Compact Class CC design fits standard industrial control enclosures
• Lighting Circuit Protection - Handles inrush currents while providing reliable overcurrent protection
• Industrial Machinery - Current limiting technology protects sensitive electronic controls
• Commercial Building Systems - Reliable protection for HVAC, elevator, and building automation circuits
• Power Distribution Panels - High interrupt rating handles utility and generator fault currents
• Transformer Secondary Protection - Time delay coordinates with upstream protective devices
• DC Control Circuits - 150VDC rating suitable for battery backup and DC drive systems

Current Limiting Technology Advantage

Bussmann current limiting technology significantly reduces let-through energy during fault conditions, protecting downstream equipment from thermal and magnetic stress. The rejection-style Class CC design ensures only properly rated fuses can be installed, preventing dangerous misapplication while providing selective coordination with upstream protective devices.

Why Choose Bussmann Quality?

Bussmann commitment to electrical safety includes rigorous testing to UL standards, NEC compliance verification, and reliable overcurrent protection performance. Each fuse undergoes comprehensive quality control testing to ensure consistent arc suppression, fault clearing capability, and long-term reliability for professional electrical installations.
