Bussmann TB100-26 Eaton TB100 series panel mount terminal block connector, Breakdown voltage 3600V, 300V, 30A, Double row, barrier, 26-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw

Bussmann TB100-26 Eaton TB100 series panel mount terminal block connector, Breakdown voltage 3600V, 300V, 30A, Double row, barrier, 26-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw

(No reviews yet) Write a Review

Model: TB100-26
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$107.66
$66.84
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann TB100-26 Eaton TB100 series panel mount terminal block connector, Breakdown voltage 3600V, 300V, 30A, Double row, barrier, 26-pole, #6-32 TPI Screw, Screw, Black, Tin-plated brass terminal, Zinc-plated Steel philslot screw.

  • Amp rating: 100 A
  • Voltage rating: 3600 V
  • Product type: Double row, barrier
  • Dimensions (L x W x H): 2.16 x 0.88 x 0.41 IN

Genuine Bussmann part number TB100-26.

Manufacturer Resources

Product Specs

Amperage Rating:
30A
Certifications:
Contact Manufacturer
Compliances:
CE Marked
Connection:
#6-32 TPI Screw
Number Of Poles:
26-pole
Operating Temperature:
-40° to 130°C
Product Height:
.41 IN
Product Length Depth:
2.16 IN
Product Weight:
.43 LB
Product Width:
.88 IN
Special Features:
Breakdown voltage 3600V
Torque Rating:
9 lb-in
Voltage Rating:
300V
Product Group:
0
Department:
Electrical
Product Subgroup:
0
Product Type:
Double row, barrier
Product Details:
Double row, barrier
Product Color:
Black
Mounting Method:
Screw
Product Material:
Tin-plated brass terminal, Zinc-plated Steel philslot screw

Bussmann TB100-26 – Frequently Asked Questions

1) What voltage and current is the Bussmann TB100-26 terminal block rated for?
The TB100-26 barrier terminal block carries a 300V working voltage rating and a 30A current rating, with a 3600V breakdown voltage. The 3600V figure is dielectric withstand, not a working voltage, so size your circuit to the 300V/30A ratings and treat the breakdown number as insulation margin only.
2) How many circuits does the TB100-26 terminal block give me?
26 poles in a double row barrier layout, so you get 26 separate barrier-isolated circuits with a screw terminal on each side of the block. That makes it a single-piece option for panel work where you would otherwise gang several smaller blocks together.
3) What screw size are the terminals on the Bussmann TB100-26, and what ring terminals fit?
Terminations are #6-32 threaded screws, so #6 ring or spade terminals land directly on them. The screws are zinc-plated steel with a Phillips/slot combination head, and the terminals themselves are tin-plated brass.
4) How tight should I torque the screws on a TB100 series barrier block?
9 lb-in on the #6-32 terminal screws. Going past that on a brass terminal with a steel screw risks stripping the thread, and going under it is the usual cause of a hot joint on a 30A circuit. Use an inch-pound driver rather than feel.
5) Will the TB100-26 hold up in an unheated outdoor enclosure or a rooftop mechanical space?
Operating range is -40 to 130 degrees C, which covers unconditioned outdoor enclosures, attic and rooftop equipment cabinets, and cold-storage panels. The block itself is not an enclosure, so it still needs to sit inside a rated box for the environment.
6) Is TB100-26 the actual Eaton part number I should order, or a house number?
TB100-26 is the genuine Eaton Bussmann part number: TB100 series, 26 poles. Order and cross-reference by that number.
7) Does a barrier-style block like this give me isolation between adjacent circuits?
Yes, that is the point of the barrier design: molded barriers stand between each of the 26 pole positions, so a stray strand or a ring terminal that rotates under its screw cannot bridge to the neighboring circuit. The black housing carries a 300V rating across those barriers with 3600V breakdown margin.
8) Is the Bussmann TB100-26 CE marked for a European-spec control panel?
The TB100-26 is CE marked. For any other agency listing on this block, Eaton is the source of record for the specific file and category.
