Eaton CH Series Handle Tie, Aluminum Bus, 225A

Eaton CH Series Handle Tie, Aluminum Bus, 225A

(No reviews yet) Write a Review

Model: CHHT

In Stock (leaves warehouse same day if ordered before 3pm ET)

$10.65
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CH Series Handle Tie, Aluminum Bus, 225A

The Eaton CH Series Handle Tie is a loadcenter and breaker accessory used with (2) single-pole CH breakers to form a 2-pole noncommon trip breaker. Rated for 225A three-phase applications with a 10 kAIC interrupt rating, this molded plastic handle cover is engineered to join two independent single-pole CH breakers so they operate together as a coordinated 2-pole unit. Housed in a NEMA 1 enclosure and UL 489 certified, it is built for reliable performance in residential and light commercial panelboard installations.

Key Features

  • Compact Dimensions: Product width of .5 in, length/depth of 1 in, and height of .5 in for a low-profile fit within the panelboard.
  • Durable Construction: Molded plastic handle cover paired with an aluminum bus material for dependable, long-lasting performance.
  • Handle Tie Type: Used with (2) single-pole CH breakers, typically joining them to form a 2-pole noncommon trip breaker.
  • Amperage Rating: 225 A rated, three-phase application.
  • Interrupt Rating: 10 kAIC for added circuit protection confidence.
  • Enclosure Rating: NEMA 1 enclosure suitable for indoor panelboard environments.

Certifications & Compliance

  • UL 489 Certified
  • NEMA 1 Enclosure Rated

Technical Specifications

  • Product Type: Load Center
  • Warranty: Limited lifetime
  • Department: Electrical

Typical Applications

  • Residential and Light Commercial Panelboard Wiring
  • Loadcenter and Breaker Accessory Upgrades
  • Joining Single-Pole CH Breakers into 2-Pole Configurations
  • Three-Phase Electrical Distribution Systems
  • New Construction and Panelboard Retrofits

Why Eaton?

Eaton engineers the CH Series Handle Tie with a durable molded plastic handle cover and aluminum bus construction backed by a limited lifetime warranty. UL 489 certification and a 10 kAIC interrupt rating give electrical professionals confidence in code-compliant, reliable performance for panelboard and breaker installations.

[{"name": "Product Type", "value": "Load Center Accessory"}, {"name": "Product Material", "value": "Aluminum"}, {"name": "Amperage Rating", "value": "225A"}, {"name": "Listing", "value": "UL 489"}, {"name": "Standards", "value": "NEMA 1"}]

Manufacturer Resources

Product Specs

Product Width:
.5 in
Used With:
(2) single-pole CH breakers
Amperage Rating:
225A
Product Length/Depth:
1 in
Special Features:
Used with (2) single-pole CH breakers
Product Height:
.5 in
Product Type:
Load Center
Phase:
Three-phase
Warranty:
Limited lifetime
Interrupt Rating:
10 kAIC
Bus Material:
Aluminum
Configuration:
NEMA 1
Certifications:
UL 489
Department:
Electrical
Product Group:
Power Distribution
Product Subgroup:
Panelboards & Load Centers
Product Length:
1 in
Product Weight:
0.01 lb

Eaton CHHT – Frequently Asked Questions

1) What does the Eaton CHHT handle tie actually do when you install it on two breakers?
The CHHT joins two single-pole Eaton CH breakers so their handles move together, giving you a 2-pole noncommon trip breaker. Both poles switch as one unit, but a fault on one pole still trips only that pole. It's a molded handle cover, not a breaker, so it adds no protection of its own.
2) Will the CHHT handle tie fit Eaton BR breakers or another brand's breakers?
No. The CHHT is made for Eaton CH breakers only, and it takes two single-pole CH breakers. Eaton's BR line uses a different handle geometry, so if your panel is loaded with BR breakers you need the BR-series handle tie instead. Same goes for Square D, Siemens or GE panels, none of those are covered here.
3) Can I use a handle tie instead of buying a real 2-pole CH breaker for a 240V circuit?
Depends on the load. A handle tie gives simultaneous disconnect but noncommon trip, which is accepted for multiwire branch circuits feeding line-to-neutral loads. For a straight 240V line-to-line load such as a water heater, dryer or A/C, code wants common trip, and that means an actual 2-pole CH breaker, not two singles with a tie. Read the tie as a disconnecting means, not a substitute for a real double-pole.
4) Is the Eaton CHHT handle tie UL listed for panel use?
It carries a UL 489 listing and is rated for NEMA 1 indoor enclosures, which is what the standard flush and surface CH loadcenter cover is. That's the pairing an inspector looks for on a field-installed tie: a listed accessory used with the breakers it was listed for.
5) What amp and interrupt ratings does the CHHT handle tie carry?
225 A, with a 10 kAIC interrupt rating, and it's rated for three-phase applications. Those figures describe the loadcenter and breaker context the tie is listed within, so if your CH panel and breakers are inside 225 A and 10 kAIC, the tie is within its rating. On a higher series-rated or 22 kAIC assembly, confirm the breaker rating drives the circuit, not the tie.
6) Can I tie two CH breakers that are not next to each other in the panel?
No. The tie is a single molded cover sized to bridge two adjacent handles, 1 in across in its longest dimension, so the breakers have to be side by side in consecutive spaces on opposite phases. If your two circuits are split across the panel, move one breaker before you order.
7) For a multiwire branch circuit in an apartment CH panel, is one CHHT enough per circuit?
One tie handles one pair of single-pole CH breakers, so a single 3-wire multiwire branch circuit needs one CHHT. If you're bringing an older building's panels up to the simultaneous-disconnect requirement, count the shared-neutral circuits and order one per pair. Buying by the pair is common on retrofit work for exactly that reason.
8) What is the CHHT made of, and does the aluminum matter for the connection?
The handle cover itself is molded plastic; the aluminum called out in the specs is the bus material of the CH loadcenter family the tie belongs to. The tie doesn't carry current, so no torque spec or anti-oxidant compound applies to it. It clips over the handles and nothing more.
9) Is the CHHT suitable for an outdoor or wet-location panel?
It's rated for NEMA 1, which is indoor, dry-location enclosures. For an exterior CH loadcenter in a rainproof NEMA 3R can, the tie sits inside the enclosure and is protected by it, but the accessory rating itself is NEMA 1, so don't plan on it in a washdown or wet interior.
10) How do I order the right Eaton CH handle tie, is there more than one version?
There's one part to specify: Eaton CHHT. No handing, no finish, no length options. Just confirm the breakers it's going over are CH single-poles and that they sit in adjacent spaces.
