Crouse-Hinds Cam-Lok J Series E1015 Angle Terminal Connector 150A 600V Female NEMA 3R

Crouse-Hinds Cam-Lok J Series E1015 Angle Terminal Connector 150A 600V Female NEMA 3R

Professional Electrical Connection Solution for Industrial Applications

The Crouse-Hinds Cam-Lok J Series E1015 Angle Terminal Connector delivers reliable electrical connections with 150A continuous amperage rating and 600 Vac/dc voltage capability. This female angle connector features durable rubber construction with NEMA 3R rating for ordinary/non-hazardous locations, accommodating #8-#4 AWG cable sizes for versatile professional installations.

Professional Features & Benefits

• 150A Continuous Rating: Handles high-current applications with reliable amperage capacity for demanding electrical systems.
• 600 Vac/dc Voltage Rating: Supports both AC and DC applications across a wide voltage range for maximum versatility.
• NEMA 3R Enclosure Rating: Provides weather-resistant protection suitable for outdoor installations and harsh environments.
• Angle Design Configuration: Space-saving 90-degree connection reduces installation footprint in tight spaces.
• Rubber Construction: Durable material provides excellent insulation properties and long-term reliability.
• NEC/CEC Compliance: Meets National Electrical Code and Canadian Electrical Code standards for professional installations.
• Female Gender Configuration: Designed for secure mating with corresponding male connectors in the Cam-Lok system.

Technical Specifications

• Amperage Rating: Up to 150A Continuous
• Area Classification: Ordinary/Non-Hazardous Locations
• Cable Size: #8-#4 AWG
• Gender: Female
• Nema Rating: 3R
• Product Height: .86 in
• Product Length Depth: 2.51 in
• Product Material: Rubber
• Product Style: Angle
• Product Weight: 1 lb
• Product Width: .86 in
• Standards Type: NEC/CEC
• Voltage Rating: 600 Vac/dc

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Industrial Power Distribution Systems
• Temporary Power Installations
• Generator Connection Points
• Equipment Interconnection
• Portable Power Applications
• Maintenance and Service Connections
• Emergency Power Systems

Why Choose Crouse-Hinds Quality?

Crouse-Hinds delivers proven reliability with NEC/CEC compliant construction and NEMA 3R weather-resistant protection. The durable rubber material and precision engineering ensure long-term performance in demanding electrical applications, backed by professional-grade quality standards.
