Eaton General-Purpose Cube Relay

Eaton General-Purpose Cube Relay

(No reviews yet) Write a Review

Model: D1RF1T1

In Stock (leaves warehouse same day if ordered before 3pm ET)

$12.30
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton DPDT General-Purpose Cube Relay, 12A, 24VDC Coil

The Eaton Cube Relay is a DPDT general-purpose relay built around a 24VDC coil and rated for 12A of switching current, making it a dependable choice for control panels, automation systems, and low-voltage DC switching applications. Housed in a compact cube-style body measuring 2 in wide, 1.5 in in length/depth, and 1 in in height, this relay is engineered to fit standard panel-mount relay sockets while delivering reliable double-pole double-throw switching. It is UL Listed and RoHS Compliant, giving electrical contractors and panel builders a code-aware component for professional-grade control wiring.

Key Features

  • DPDT Configuration: Double-pole, double-throw contact arrangement allows this relay to control two separate circuits simultaneously from a single coil signal, simplifying control logic in panels and machine wiring.
  • 12A Contact Rating: Rated to switch up to 12A, suitable for general-purpose control loads found in industrial automation, HVAC controls, and machine control circuits.
  • 24VDC Coil Voltage: Operates on a 24 Vdc coil, aligning with the common low-voltage DC control standard used throughout industrial and commercial control systems.
  • Compact Cube Footprint: Product dimensions of 2 in width by 1.5 in length/depth by 1 in height allow the relay to fit into space-constrained panel layouts and standard relay sockets.
  • General-Purpose Relay Type: Designed as a general-purpose relay for broad application across control, automation, and switching tasks where a compact, reliable relay is required.
  • RoHS Compliant Construction: Manufactured to meet RoHS compliance standards, supporting environmentally conscious procurement and installation requirements.

Certifications & Compliance

  • UL Listed
  • RoHS Compliant

Technical Specifications

  • Department: Electrical
  • Product Width: 2 in
  • Coil Voltage: 24 Vdc
  • Product Length/Depth: 1.5 in
  • Compliances: RoHS Compliant
  • Product Height: 1 in
  • Type: General-purpose relay
  • Certifications: UL Listed

Typical Applications

  • Industrial Control Panels
  • Automation and Process Control Systems
  • Machine Control Wiring
  • Low-Voltage DC Switching Circuits
  • Panel-Mount Relay Socket Installations
  • Commercial and Industrial Electrical Control Systems

Why Eaton?

Eaton engineers this DPDT cube relay with a defined 12A contact rating and 24VDC coil so panel builders and electricians can specify switching behavior with confidence. Its UL Listed and RoHS Compliant status reflects a construction standard built for professional, code-compliant electrical work. For control panels, automation systems, and general-purpose switching applications that demand a compact, reliable relay, the Eaton Cube Relay is a practical, standards-backed choice.

Manufacturer Resources

Product Specs

Department:
Electrical
Certifications:
UL Listed
Compliances:
RoHS Compliant
Product Type:
Relay
Configuration:
DPDT
Amperage Rating:
12A
Voltage Rating:
24VDC
Listing:
UL Listed
Standards:
RoHS Compliant
Product Group:
Motor Control & Automation
Product Subgroup:
Contactors & Relays

Eaton D1RF1T1 – Frequently Asked Questions

1) What contact configurations and coil voltages does the Eaton cube relay come in?
Three combinations are offered on the Eaton general-purpose cube relay: SPDT rated 15A with a 24VDC coil (D1RF1T1), DPDT rated 12A with a 24VDC coil (D2RF2T1), and 4PDT rated 6A with a 120VAC coil (D2RF4A). Note that contact rating drops as pole count goes up, so pick the pole count you need for your control logic first, then confirm the load current sits under that pole's rating.
2) Can I run this Eaton cube relay off a 24VDC PLC output?
Yes, for the SPDT and DPDT versions. Both use a 24 Vdc coil, which is the standard low-voltage DC control level used on most PLC and machine control panels. If your control circuit is 120VAC instead, the 4PDT version is the one with a 120VAC coil.
3) I need to switch two separate circuits from one signal. Which Eaton cube relay should I order?
The DPDT version, part D2RF2T1. A double-pole double-throw contact set lets one coil signal control two independent circuits at once, each with a normally open and normally closed path. It switches up to 12A per the contact rating. If you need four circuits, step up to the 4PDT D2RF4A, but its contacts are rated 6A and its coil is 120VAC.
4) Can the Eaton cube relay handle a 14A load?
Only the SPDT version, D1RF1T1, which is rated 15A. The DPDT is rated 12A and the 4PDT 6A, so a 14A load exceeds both. For higher currents on a multi-pole circuit, use the relay as a pilot device driving a contactor rather than switching the load directly.
5) Will the Eaton cube relay fit a standard panel-mount relay socket?
It is built as a cube-style relay sized for standard panel-mount relay sockets, with a body of 2 in wide by 1.5 in length/depth by 1 in high. Confirm your socket matches the pin pattern for the pole count you order, since the SPDT, DPDT and 4PDT versions do not share a blade layout.
6) Is the Eaton cube relay UL Listed and RoHS compliant?
Both. The cube relay is UL Listed and RoHS Compliant, which is usually what a facility or government spec is looking for on control panel components.
7) Is a general-purpose cube relay the right choice for HVAC and machine control, or do I need something else?
A general-purpose relay like this one is the normal pick for control-level work: interposing between a controller output and a contactor or valve, HVAC control circuits, and machine control wiring. It is not a motor starter or a power contactor, so anything drawing more than the contact rating (15A SPDT, 12A DPDT, 6A 4PDT) should be handled by a contactor with the relay acting as the pilot.
