Eaton D4PR21T D4 Series Genera...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$89.79
$39.79
Eaton D4PR21T D4 Series General Purpose Plug-In Relay, QTY: 1, 24V coil, DPDT contact configuration, 5 A, 240 Vac/30 Vdc resistive load, 2 A, 250 Vac/3 A, 30 Vdc inductive full load, 5A amperage rating, 380 Vac/125 Vdc max. operating voltage

Eaton D4PR21T D4 Series General Purpose Plug-In Relay, QTY: 1, 24V coil, DPDT contact configuration, 5 A, 240 Vac/30 Vdc resistive load, 2 A, 250 Vac/3 A, 30 Vdc inductive full load, 5A amperage rating, 380 Vac/125 Vdc max. operating voltage

(No reviews yet) Write a Review

Model: D4PR21T
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$89.79
$39.79
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton D4 Series General Purpose Plug-In Relay, QTY: 1, 24V coil, DPDT contact configuration, 5 A, 240 Vac/30 Vdc resistive load, 2 A, 250 Vac/3 A, 30 Vdc inductive full load, 5A amperage rating, 380 Vac/125 Vdc max. operating voltage

Manufacturer Resources

Product Specs

Amperage Rating:
5A
Catalog Notes:
Indicator lamp available. Consult sales office or customer support center for additional coil voltages.
Certifications:
cRUus
Coil Voltage:
24 V
Compliances:
RoHS Compliant
Contact Configuration:
DPDT
Indicators:
Indicating light
Inductive Full Load:
2 A at 250 Vac, 3 A at 30 Vdc
Product Height:
1.1 in
Product Length Depth:
1.14 in
Product Weight:
.05 lb
Product Width:
.51 in
Quantity:
1
Resistive Load:
5 A, 240 Vac, 30 Vdc
Series:
D4
Voltage Max:
380 Vac/125 Vdc
Product Group:
Electrical
!
