Eaton E50ANS26P E50 Heavy Duty...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$756.26
$706.26
Eaton E50ANS26P E50 Heavy Duty Factory Sealed 6P+ Limit Switch,Within 0.003,8ft.(2.5m)Cable,10Aat240Vac,1Aat125Vdc,SOOW-A,1NO-1NC,96ft,Die Cast Zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,IP69K,Neon(120Vac),10A,1A,14°to201°F,Adj. Side Pushbuttn

Eaton E50ANS26P E50 Heavy Duty Factory Sealed 6P+ Limit Switch,Within 0.003,8ft.(2.5m)Cable,10Aat240Vac,1Aat125Vdc,SOOW-A,1NO-1NC,96ft,Die Cast Zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,IP69K,Neon(120Vac),10A,1A,14°to201°F,Adj. Side Pushbuttn

(No reviews yet) Write a Review

Model: E50ANS26P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$756.26
$706.26
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton E50 Heavy Duty Factory Sealed 6P+ Limit Switch,Within 0.003,8ft.(2.5m)Cable,10Aat240Vac,1Aat125Vdc,SOOW-A,1NO-1NC,96ft,Die Cast Zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,IP69K,Neon(120Vac),10A,1A,14°to201°F,Adj. Side Pushbuttn

Manufacturer Resources

Product Specs

Accuracy:
Within 0.003
Cable Type:
SOOW-A
Certifications:
UL Listed
Compliances:
CE Marked
Connection:
8 ft (2.4 m) cable
Contact Configuration:
1 NO-1 NC
Contact Rating:
10A at 240Vac, 1A at 125Vdc
Cord Length:
96 ft
Enclosure Material:
Die cast zinc
Environmental Rating:
NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67, IP69K
Led Indicator:
Neon (120 Vac)
Maximum Ac Current:
10:00 AM
Maximum Dc Current:
1:00 AM
Operating Temperature Max:
201 °F
Operating Temperature Min:
14 °F
Product Height:
4.67 in
Product Length Depth:
1.54 in
Product Weight:
2.1 lb
Product Width:
2.79 in
Switch Type:
Adjustable side pushbutton
!
