Eaton E50 NEMA Heavy-Duty Side Rotary Limit Switch, Stainless Steel Lever Operator

Eaton E50 Heavy-Duty NEMA Limit Switch Operator

The Eaton E50 Heavy-Duty NEMA Limit Switch Operator is a plug-in lever-style operator built for side rotary limit switches in demanding industrial environments. Available in a range of enclosure materials to suit corrosive, wet, and washdown conditions, this operator is rated NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, and NEMA 13, plus IP67 and IP69K, for reliable performance across a wide range of indoor, outdoor, and washdown applications. With an operating temperature range of -40 °F to 201 °F and UL Listed certification, the Eaton E50 delivers dependable position-sensing performance where standard operators cannot withstand harsh conditions.

Key Features

• Durable Construction: Robust operator materials provide corrosion resistance and long service life in industrial settings.
• Switch Type: Lever for side rotary switches, designed as a plug-in operator for quick installation.
• Environmental Rating: NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67, and IP69K for use in wet, dusty, and washdown locations.
• Operating Temperature: Rated from -40 °F to 201 °F for use across extreme hot and cold conditions.
• RoHS Compliant: Manufactured to meet RoHS restricted-substance requirements.
• Backed Warranty: Covered by a 1 year manufacturer warranty for added peace of mind.

Certifications & Compliance

• UL Listed
• RoHS Compliant
• NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13
• IP67 and IP69K Rated

Technical Specifications

• Warranty: 1 year
• Switch Type: Lever for side rotary switches
• Operating Temperature - Min: -40 °F
• Operating Temperature - Max: 201 °F
• Environmental Rating: NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67, IP69K
• Certifications: UL Listed
• Compliances: RoHS Compliant
• Catalog Notes: Lever length is measured from the operating shaft axis to the roller axis

Typical Applications

• Industrial Machine Safety Interlocks
• Conveyor and Material Handling Systems
• Heavy-Duty NEMA-Rated Industrial Environments
• Outdoor and Washdown Locations
• Position Sensing for Side Rotary Limit Switches
• Extreme Temperature Applications

Why Eaton?

Eaton engineers the E50 limit switch operator with rugged enclosure materials and multi-NEMA, IP67, and IP69K environmental ratings to withstand corrosive, wet, and washdown conditions that would degrade lesser components. UL Listed and RoHS Compliant, this operator is built for code-compliant performance in demanding industrial and commercial electrical systems, backed by Eaton's 1 year warranty for reliable, long-term operation.

Variant Specifications
