Eaton E51 Series Timer Module, Plastic enclosure
Manufacturer Resources
Product Specs
- Catalog Notes:
- Assembled sensor with head; sensor body and receptacle. Requires glass fiber optic cables for operation.
- Certifications:
- CSA Certified
- Compliances:
- CE Marked
- Connection:
- Screw terminal
- Contact Configuration:
- Complementary NPN open collector
- Contact Rating:
- 600 mA
- Enclosure Material:
- Receptacle and body: die cast zinc
- Environmental Rating:
- NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67
- Input Voltage:
- 10-30 Vdc
- Led Indicator:
- Lights when output is ON
- Maximum Dc Current:
- 600 mA
- Operating Mode:
- Fiber-optic
- Operating Temperature Max:
- 158 °F
- Operating Temperature Min:
- -13 °F
- Product Height:
- 4.89 in
- Product Length Depth:
- 1.54 in
- Product Weight:
- .975 lb
- Product Width:
- 1.82 in
- Sensor Type:
- Fiberoptic
- Switch Type:
- Photoelectric
- Product Group:
- Electrical
