Eaton AFCI Circuit Breaker 15A Single-Pole 120V 10kAIC BR Series Plug-On Neutral

Eaton AFCI Circuit Breaker 15A Single-Pole 120V 10kAIC BR Series Plug-On Neutral

Professional Arc Fault Circuit Interrupter Protection

The Eaton AFCI Circuit Breaker delivers exceptional arc fault protection and electrical safety performance for residential and commercial electrical systems. This 15A single-pole 120V circuit breaker provides reliable arc fault circuit interruption designed for professional electricians, electrical contractors, and facility managers, offering the proven reliability and advanced AFCI technology that professionals trust from the global leader in intelligent power management.

Professional Features & Benefits

Arc Fault Protection Performance

• 15A Single-Pole Configuration - Optimal current capacity for standard residential branch circuits with reliable single-pole switching and Eaton electrical performance
• 120V Voltage Rating - Designed for standard residential voltage applications with precise voltage protection and electrical safety
• 10kAIC Interrupt Rating - Professional interrupting capacity for reliable fault current protection in residential electrical systems
• AFCI Combination Technology - Advanced arc fault detection and interruption for enhanced electrical fire prevention and safety

Installation & Connection Features

• Plug-On Neutral Design - Simplified installation with integrated neutral connection for faster professional installation
• BR Series Compatibility - Engineered specifically for Type BR loadcenters ensuring perfect fit and electrical performance
• #14-8 AWG Cu/Al Wire Compatibility - Versatile wire size accommodation for various residential wiring applications

Technical Specifications

Amperage Rating: 15A, Voltage Rating: 120V, Number of Poles: Single-pole, Interrupt Rating: 10kAIC, Wire Size: #14-8 AWG Cu/Al, Connection: Plug-on, Neutral: Plug-on neutral, Used With: Type BR Loadcenters, Special Features: UL only, Certifications: UL Listed, Product Dimensions: 2.56" L x 1.1" H x 1" W, Product Weight: 0.38 lb

Installation & Usage

1. Verify power is OFF and test electrical panel before beginning installation procedures
2. Remove knockout from Type BR loadcenter and position AFCI circuit breaker in designated slot
3. Connect hot wire to circuit breaker terminal ensuring proper torque specifications
4. Engage plug-on neutral connection to loadcenter neutral bus for AFCI functionality
5. Verify proper seating and electrical connections before energizing circuit
6. Test AFCI function using test button to confirm proper arc fault protection operation

Professional Applications

Ideal for:

• Residential Branch Circuits - Bedrooms, living rooms, family rooms, dining rooms, and other habitable spaces requiring AFCI protection
• NEC Code Compliance - Meeting National Electrical Code requirements for arc fault circuit interrupter protection in dwelling units
• Electrical Fire Prevention - Advanced protection against electrical fires caused by arc faults in residential wiring systems
• New Construction Projects - Professional installation in new residential electrical systems requiring AFCI protection
• Electrical Panel Upgrades - Retrofitting existing BR loadcenters with modern arc fault protection technology
• Electrical Safety Enhancement - Upgrading standard circuit breakers to AFCI protection for improved electrical safety
• Professional Electrical Services - Electrical contractor installations requiring reliable AFCI circuit protection
• Code Inspection Compliance - Meeting electrical inspection requirements for AFCI protection in residential applications

AFCI Technology Advantage

Eaton's AFCI combination technology provides superior arc fault detection and interruption capabilities, protecting against both parallel and series arc faults that can cause electrical fires. The advanced electronic sensing technology continuously monitors electrical current patterns and quickly interrupts circuits when dangerous arc fault conditions are detected, providing enhanced electrical safety beyond traditional circuit breaker protection.

Why Choose Eaton Quality?

With over a century of electrical power management innovation, Eaton delivers the advanced AFCI technology and proven reliability that electrical professionals trust. Our UL Listed AFCI circuit breakers meet the highest electrical safety standards and provide dependable arc fault protection for residential electrical systems. Trusted by electricians, electrical contractors, and facility professionals worldwide, Eaton continues to lead in electrical safety innovation and intelligent power management solutions.
