Eaton CN55AN3AB Freedom NEMA m...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,914.26
$1,864.26
Eaton CN55AN3AB Freedom NEMA motor control contactor, NEMA Freedom Series Reversing contactor, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50 Hz coil voltage, 9A, Three-pole, Size 00

Eaton CN55AN3AB Freedom NEMA motor control contactor, NEMA Freedom Series Reversing contactor, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50 Hz coil voltage, 9A, Three-pole, Size 00

(No reviews yet) Write a Review

Model: CN55AN3AB
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,914.26
$1,864.26
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton CN15AN3AB Freedom NEMA motor control contactor, NEMA Freedom Series Non-Reversing contactor, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50 Hz coil voltage, 9A, Three-pole, Size 00

Eaton CN15AN3AB Freedom NEMA motor control contactor, NEMA Freedom Series Non-Reversing contactor, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50 Hz coil voltage, 9A, Three-pole, Size 00

Model: EAT-CN15AN3AB

Eaton Freedom NEMA motor control contactor, NEMA Freedom Series Non-Reversing contactor, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50...

Eaton

$774.30
$724.30
Eaton Freedom NEMA motor control contactor, NEMA Freedom Series Reversing contactor, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 120V/60 Hz or 110V/50 Hz coil voltage, 9A, Three-pole, Size 00

Manufacturer Resources

Product Specs

Amperage Rating:
9A
Catalog Notes:
Common Control
Certifications:
UL Listed
Coil Voltage:
110-120 Vac, 50/60 Hz
Hp Rating Max:
1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V
Number Of Poles:
Three-pole
Phase:
Single-phase, three-phase
Product Height:
3.88 in
Product Length Depth:
3.49 in
Product Weight:
3.1 lb
Product Width:
1.75 in
Size:
0
Product Group:
Electrical
!
