Eaton Freedom Series Three-Pole Reversing Motor Control Contactor, 9A

Eaton Freedom Series Three-Pole Reversing Motor Control Contactor, 9A

(No reviews yet) Write a Review

Model: CN55AN3BB

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,249.93
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Freedom Series Three-Pole Reversing Motor Control Contactor, 9A

The Eaton Freedom Series Three-Pole Reversing Motor Control Contactor is a Size 0 common-control contactor built for dependable motor switching in industrial and commercial power distribution systems. Rated 9A with a 220-240 Vac, 50/60 Hz coil, this three-pole, single-phase/three-phase contactor is CSA Certified and sized for compact panel and enclosure layouts. It is designed to provide reliable reversing motor control for pumps, fans, conveyors, and other motor-driven equipment where consistent, code-compliant switching performance is required.

Key Features

  • Three-Pole Configuration: Three-pole design supports single-phase and three-phase motor control circuits.
  • Compact Size 0 Footprint: Product dimensions of 1.75 in width, 3.49 in depth, and 3.88 in height for space-efficient panel mounting.
  • Amperage Rating: 9A rated for common-control motor switching applications.
  • Coil Voltage: 220-240 Vac, 50/60 Hz coil for standard control circuit compatibility.
  • Reversing Configuration: Common-control reversing design simplifies forward/reverse motor switching in a single assembly.
  • HP Rating: Rated 1/3 hp at 115V, 1 hp at 230V, 1-1/2 hp at 208V/240V, and 2 hp at 480V/600V for flexible motor sizing.
  • Dual-Phase Compatibility: Suitable for single-phase and three-phase motor circuits.

Certifications & Compliance

  • CSA Certified

Technical Specifications

  • Amperage Rating: 9A
  • Size: 0
  • Department: Electrical

Typical Applications

  • Industrial Motor Control Panels
  • Commercial HVAC and Pump Motor Switching
  • Reversing Motor Control for Conveyors and Fans
  • Panelboard and Control Cabinet Wiring
  • Renovation and New Construction Electrical Installations

Why Eaton?

Eaton's Freedom Series contactors are engineered for dependable, code-compliant motor control performance backed by CSA Certification. With a compact Size 0 footprint, common-control reversing configuration, and a defined 9A amperage rating with 220-240 Vac coil, this contactor is built to deliver consistent switching reliability for professional electrical and motor control installations.

Manufacturer Resources

Product Specs

Number Of Poles:
Three-pole
Product Width:
1.75 in
Catalog Notes:
Common Control
Amperage Rating:
9A
Coil voltage:
220-240 Vac, 50/60 Hz
Product Size:
0
Product Length/Depth:
3.49 in
Product Height:
3.88 in
Phase:
Single-phase, three-phase
Certifications:
CSA Certified
Product Type:
Contactor
Department:
Electrical
Voltage Rating:
220-240V
Configuration:
Reversing
Standards:
CSA Certified
Product Group:
Starters & Contactors

Eaton CN55AN3BB – Frequently Asked Questions

1) Will the Eaton Freedom CN55AN3BB contactor run my motor, and what horsepower does it handle?
The CN55AN3BB is a 9A Size 0 reversing contactor rated 1/3 hp at 115V, 1 hp at 230V, 1-1/2 hp at 208V/240V, and 2 hp at 480V/600V. Size your motor's full load amps and voltage against those figures. If your motor exceeds them, you need a larger frame size than a Size 0.
2) What control voltage does the Eaton CN55AN3BB coil need?
The coil is 220-240 Vac, 50/60 Hz. It will not pull in reliably off a 120V control transformer, so if your control circuit is 120V you need a different coil voltage version. The 50/60 Hz rating means it works on either line frequency.
3) Do I need two contactors and an interlock to reverse a motor, or does this Eaton unit do it in one piece?
One piece. The CN55AN3BB is a common-control reversing contactor, so the forward and reverse switching is built into a single assembly instead of two separate contactors you have to wire and interlock yourself. That is the difference between this and a standard non-reversing Freedom contactor, which only switches a motor in one direction.
4) How much panel space does the Eaton Freedom Size 0 reversing contactor take up?
It measures 1.75 in wide, 3.49 in deep, and 3.88 in high. Lay that out against your DIN rail or backpan run before you commit, and leave room for the wiring gutter and any overload relay you are stacking on it.
5) Can I use a three-pole contactor like this on a single-phase motor circuit?
Yes. The CN55AN3BB is three-pole and rated for both single-phase and three-phase motor circuits. On single-phase you switch two of the poles for the line conductors; on three-phase all three carry a leg.
6) Is the Eaton CN55AN3BB listed for use in commercial and industrial control panels?
It carries CSA Certification. That is the rating stated for this contactor, and it is the one to cite when a panel is being reviewed for Canadian jurisdiction work.
7) What is the exact Eaton part number for this 9A reversing Freedom contactor?
Eaton catalog number CN55AN3BB. That is the Size 0, three-pole, common-control reversing contactor with the 220-240 Vac coil. Quote that number when you are matching an existing panel so you get the same coil voltage back.
8) Is this contactor suitable for a pump or conveyor that has to run both directions?
That is exactly what it is built for. The reversing configuration handles forward and reverse switching for pumps, fans, conveyors, and similar motor-driven equipment, within the 9A rating and the stated horsepower limits for your supply voltage.
