Product Specs
- Amperage Rating:
- 105A
- Coil Voltage:
- 24 VAC, 50/60 Hz
- Frame Size:
- M-frame
- Frequency Rating:
- 60 Hz
- Notes:
- No enclosure
- Number Of Poles:
- Two-pole
- Operation:
- Non-reversing
- Relay:
- No overload relay
- Series:
- Freedom
- Department:
- Electrical
- Product Type:
- Contactor
- Product Length:
- 5.94 IN
- Product Details:
- Contactor
- Mounting Method:
- Steel mounting plate
- Product Height:
- 7.17 IN
- Product Weight:
- 8.05 LB
- Product Width:
- 4.08 IN
B-LINE CE15MN2T – Frequently Asked Questions
1) Will the CE15MN2T contactor work with a 24V control circuit?
Yes. The CE15MN2T Freedom series contactor has a 24 VAC coil rated 50/60 Hz, so it drops straight onto a 24 volt AC control transformer or thermostat circuit. If your control power is 120V or 277V, this is the wrong coil and you need a different coil voltage version.
2) Does the CE15MN2T contactor include overload protection for a motor?
No. The CE15MN2T ships with no overload relay, so it is a bare contactor, not a starter. If you are switching a motor and need running overload protection, you have to add a separate overload relay sized to the motor FLA or use a combination starter instead.
3) Is the Eaton Freedom CE15MN2T supplied in an enclosure?
It is an open, panel-mount device with no enclosure. It comes on a steel mounting plate, so plan on installing it inside an existing control panel, MCC bucket, or a separately purchased NEMA enclosure rated for the location.
4) How many poles does the CE15MN2T contactor switch, and can I use it on a three-phase motor?
Two poles only. That makes the CE15MN2T suited to single-phase loads, resistive heating banks, and lighting circuits where two lines are switched. A three-phase motor load needs a three-pole contactor instead, since all three legs have to be broken.
5) What current can the CE15MN2T Freedom contactor carry?
It is rated 105A and is an M-frame device in Eaton's Freedom IEC line. That amperage is the sizing number to check against your load current and the upstream breaker before you commit to this frame.
6) How much panel space do I need for the CE15MN2T contactor?
Allow for a device measuring 7.17 x 5.94 x 4.08 inches (height, length, width) weighing 8.05 lb. At that mass the steel mounting plate wants a solid subpanel rather than a light DIN rail run, and you should leave clearance above and below for the line and load terminations.
7) Can I use the CE15MN2T to reverse a motor?
No. The CE15MN2T is a non-reversing contactor, a single unit with no mechanical interlock or second power block. Reversing duty needs a reversing contactor pair or a reversing starter assembly.
8) Will the CE15MN2T run on 50 Hz power for an export panel?
The coil is listed at 24 VAC, 50/60 Hz, so the control circuit handles either frequency. The device itself carries a 60 Hz frequency rating, which is the figure to work from when specifying for North American power.
